Description
The Payne PA5SAN53000W-PF5MNXB30L00 bundle combines a PA5SAN5 single-stage outdoor air conditioner with a PF5M fan coil for ducted, whole-home cooling. It’s intended for standard split-system central AC applications where the buyer wants simple operation and broad service familiarity. Keeping the full pairing, Payne PA5SAN53000W-PF5MNXB30L00, front and center helps both consumers and pros shop the correct matched bundle instead of mixing components.
Payne positions the PA5SAN5 series as their most energy-efficient single-stage air conditioner, offering up to 16.5 SEER2 and up to 14.5 EER2 depending on indoor match. The series is also positioned for quiet performance with sound as low as 71 decibels on the quietest size within each model group during the most common cooling operating condition. Practical protection features include a system-protecting filter drier, a tight-wire grille that allows easier coil cleaning, and a weather-protected galvanized steel cabinet.
The PF5M fan coil is positioned to improve comfort consistency through airflow flexibility. Payne highlights a multi 5-speed high-efficiency blower motor designed to quietly deliver more even levels of temperature control. PF5M also includes a TXV, a fully insulated galvanized steel cabinet, a corrosion-resistant all-aluminum coil, a corrosion-free sloped drain pan design to help reduce condensate buildup, and a factory-installed refrigerant leak dissipation system to meet newer UL requirements. Both product families are positioned with lower global warming potential R-454B refrigerant.
Key Features
-
Payne PA5SAN53000W single-stage cooling: Efficient, straightforward compressor operation in a conventional ducted split system.
-
Up to 16.5 SEER2 / up to 14.5 EER2 (match-dependent): Published “up to” efficiency varies by indoor pairing.
-
Sound as low as 71 dB (series positioning): Quiet-performance positioning depending on size and conditions.
-
Filter drier + protective coil grille: System protection and durability-focused cabinet/coil guard features.
-
PF5MNXB30L00 5-speed high-efficiency blower: Airflow flexibility to support more even temperatures and quieter air delivery.
-
PF5M TXV + all-aluminum coil: Thermostatic expansion valve and corrosion-resistant coil construction.
-
PF5M insulated cabinet + sloped drain pan: Fully insulated cabinet and condensate-management focused pan design.
-
R-454B + UL leak dissipation system: Lower-GWP refrigerant positioning and factory leak dissipation system on PF5M.
