Description
The Payne PA5SAN54200W-PF5MNXC42L00 bundle matches a PA5SAN5 single-stage outdoor air conditioner with a PF5M fan coil for ducted, whole-home cooling in a conventional central AC format. This is aimed at buyers who want the reliability and simplicity of a single-stage split system while still getting indoor airflow flexibility to help the home feel more even. Using the full pairing, Payne PA5SAN54200W-PF5MNXC42L00, keeps the selection focused on a matched system approach.
Payne positions the PA5SAN5 line as their most energy-efficient single-stage air conditioner with up to 16.5 SEER2 and up to 14.5 EER2 depending on the indoor match. They also position the series for quiet performance, with sound as low as 71 decibels on the quietest size within each model group during the most common cooling operating condition. Protection features include a system-protecting filter drier, a durable tight-wire grille that allows easier coil cleaning, and a galvanized steel cabinet with weather-protective paint.
The PF5M fan coil is positioned around comfort consistency, using a multi 5-speed high-efficiency blower motor designed to quietly deliver more even levels of temperature control. PF5M is also positioned with a TXV, a fully insulated galvanized steel cabinet, a corrosion-resistant all-aluminum coil, and a corrosion-free sloped drain pan design to help reduce condensate buildup. It includes a factory-installed refrigerant leak dissipation system to meet newer UL requirements. Both product families are positioned with lower global warming potential R-454B refrigerant.
Key Features
-
Payne PA5SAN54200W single-stage cooling: Efficient single-stage compressor operation in a conventional split-system format.
-
Up to 16.5 SEER2 / up to 14.5 EER2 (match-dependent): Published “up to” efficiency varies by indoor pairing.
-
Sound as low as 71 dB (series positioning): Quiet-performance positioning varies by size and conditions.
-
Filter drier + protective coil grille: System protection plus durable grille designed for easier coil cleaning.
-
PF5MNXC42L00 5-speed high-efficiency blower: Multi-speed airflow flexibility for more even temperatures.
-
PF5M TXV + corrosion-resistant all-aluminum coil: Stable refrigerant metering and durable coil construction.
-
PF5M insulated cabinet + sloped drain pan: Fully insulated cabinet and condensate-management focused pan design.
-
R-454B + UL leak dissipation system: Lower-GWP refrigerant positioning and factory leak dissipation system on PF5M.
