ClimateMaster 5 Ton 13.2 EER Horizontal Water Source Heat Pump System Left Return R454B Refrigerant 460V 3-Phase | SCL060ALC3ZC0PS

ClimateMaster

5 Star RatingLeave a review
No reviews yet Write a Review
SKU:
SCL060ALC3ZC0PS
Your Price $0.00

Detecting ZIP...
Est. Net Incentive Amount: $0.00
We could not detect your ZIP automatically. Enter your ZIP to check incentives.
Available Incentives
$0.00
Selected Incentives
0
Unpriced Programs
0
Estimates assume eligibility; programs and amounts can change.
Condition:
New
Width:
24.10 (in)
Height:
21.00 (in)
Depth:
54.10 (in)

Questions about ClimateMaster 5 Ton 13.2 EER Horizontal Water Source Heat Pump System Left Return R454B Refrigerant 460V 3-Phase | SCL060ALC3ZC0PS?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business

Fast Shipping

Customer Support

Warranty Coverage

Financing Available

$7,141.00

  • Qualifies for FREE Shipping
in stock • Ships in 9-10 Weeks
Overview

ClimateMaster 5 Ton 13.2 EER Horizontal Water Source Heat Pump System Left Return R454B Refrigerant 460V 3-Phase | SCL060ALC3ZC0PS

ClimateMaster 5 Ton 13.2 EER Horizontal Water Source Heat Pump System Left Return Cupro-Nickel Coil R454B Refrigerant 460V 3-Phase, model SCL060ALC3ZC0PS
Product details

Description

The ClimateMaster SCL060ALC3ZC0PS is a 5 Ton (59,400 BTU/h) Tranquility 18 SC compact single-stage water source heat pump in a horizontal, straight-discharge cabinet with left return air. It is built for 460V 3-Phase power and uses a copper coaxial water coil, the standard choice for closed-loop systems with clean, properly treated water. 4 COP (AHRI 214841667), moving 2,000 CFM with a PSC blower and up to 15 GPM through 1" FPT water connections. This 5-ton model ships with the factory Refrigerant Detection System (RDS) required for R-454B equipment of this charge size.

The Tranquility 18 SC Compact Single-Stage Series is a high-efficiency geothermal solution engineered to achieve performance beyond ASHRAE 90.1 standards using Earth-friendly R-454B refrigerant. Designed with a compact cabinet, this unit installs easily in tight spaces while offering flexible configurations for both horizontal and vertical installations. A double-isolation compressor mount, combined with sound-absorbing insulation, ensures whisper-quiet operation, even during start-up and steady state runs. Enhanced with building-management system (BMS) compatibility—including BACnet, Modbus, and Johnson Controls N2—it integrates smoothly into commercial HVAC ecosystems. Optional features like Refrigerant Detection System (RDS), EC motor configurations, and UltraQuiet packages allow customization along with backward compatibility for retrofit applications. Key Features:
  • Half-to-5 ton capacity range (006–060 sizes) for flexible sizing
  • R-454B low-GWP refrigerant, exceeding ASHRAE 90.1 efficiency standards
  • Double-isolation compressor mounting with acoustic insulation for low noise
  • Compact footprint with field-convertible discharge for horizontal or vertical installations
  • BMS-ready: supports BACnet, Modbus, and Johnson Controls N2 communication protocols
  • Optional Refrigerant Detection System (mandatory on 060, optional on others)
  • Choice of Constant Volume (CV) or Constant Torque (CT) EC motors with UltraQuiet package
  • Non-corrosive polymer drain pan and robust safety feature set
TL;DR:
  • Compact, quiet geothermal unit covering 1/2 – 5 tons
  • R-454B refrigerant; exceeds ASHRAE 90.1 efficiency
  • BMS-compatible for modern commercial control
  • Customizable with EC motors, RDS, and noise-attenuation options

White Paper

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
ClimateMaster
Width:
24.10 (in)
Height:
21.00 (in)
Depth:
54.10 (in)
Weight:
285.00 LBS
AHRI Certified:
Yes
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Capacity (Tons):
5
Airflow (CFM):
2,000
Blower Motor Type:
PSC
Breaker Size (Amps):
15
Connection Type:
FPT
Configuration:
Horizontal
Color:
Gray
Product Category:
Water Source Heat Pump
Electrical Phase:
3-Phase
Minimum Circuit Ampacity (MCA):
11.3
Electrical Frequency:
60 Hz
Prop 65 Warning:
Yes
Refrigerant Type:
R-454B
Return Air / Filter Location:
Left Return
Cooling Capacity (BTU):
59,400
AHRI Reference Number:
214841667
Compressor Stages:
Single Stage
Heating BTU | Ground Water:
59,200
EER | Ground Loop:
15.0
Heating BTU | Ground Loop:
45,400
Flow (GPM):
15
EER | Water Loop:
13.2
EER | Ground Water:
18.2
Loop In/Out FPT:
1”
Heating BTU | Water Loop:
70,000
Maximum Overcurrent Protection (MOP):
15
Product Line:
SC
Shipping Weight:
285 lb
Package Type:
Water Source
Voltage / Phase:
460V 3-Phase
COP | Water Loop:
4.4
COP | Ground Water:
3.9
COP | Ground Loop:
3.3
Unit Weight:
278 lb
Water Coil Material:
Copper
Refrigerant Charge (oz):
69
Compressor Type:
Scroll
Refrigerant Detection System (RDS):
Included
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
1 Year Parts
Videos2 videos
ClimateMaster: 50+ Years of Geothermal Heat Pump Innovation
Frequently asked questions
What size is the ?
The is a 5 ton unit.
What refrigerant does the use?
It uses R-454B refrigerant.
How much cooling does the provide?
It is rated for 59,400 BTU of cooling.
Is the AHRI certified?
Yes. The AHRI reference number is 214841667.
What power supply does the need?
It requires 460V 3-Phase power.
What warranty comes with the SCL060ALC3ZC0PS?
1 Year Parts
Who makes the SCL060ALC3ZC0PS?
The SCL060ALC3ZC0PS is made by ClimateMaster.
