Comfortstar 12,000 BTU 17 SEER2 Ductless Mini Split Heat Pump with R32 Eco Smart Series with Wifi 115V | CH32-12CA

Comfortstar

5 Star RatingLeave a review
No reviews yet Write a Review
SKU:
CH32-12CA
Your Price $0.00

Detecting ZIP...
Est. Net Incentive Amount: $0.00
We could not detect your ZIP automatically. Enter your ZIP to check incentives.
Available Incentives
$0.00
Selected Incentives
0
Unpriced Programs
0
Estimates assume eligibility; programs and amounts can change.
Condition:
New
Width:
27.56 (in)
Height:
20.08 (in)
Depth:
11.89 (in)

Questions about Comfortstar 12,000 BTU 17 SEER2 Ductless Mini Split Heat Pump with R32 Eco Smart Series with Wifi 115V | CH32-12CA?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business

Fast Shipping

Customer Support

Warranty Coverage

Financing Available

$805.95

  • Qualifies for FREE Shipping
5 in stock • Ships in 2-4 Business days
Overview

Comfortstar 12,000 BTU 17 SEER2 Ductless Mini Split Heat Pump with R32 Eco Smart Series with Wifi 115V | CH32-12CA

Complete system: Comfortstar 12,000 BTU 17 SEER2 Ductless Mini Split Heat Pump with R32 Eco Smart Series with Wifi 115V
Product details

Description

The ComfortStar CH32‑12CA is a 12,000 BTU R32 heat pump mini-split in the CH32 Eco Smart Series. It delivers up to 17 SEER2 cooling efficiency and HSPF2 of 9.5 (Region IV), operating on 115 V/60 Hz power. Designed as a high-wall mounted system, it pairs a compact indoor head with a small outdoor condenser unit measuring approximately 31"×11"×20". The inverter compressor and electronic expansion valve enhance responsiveness and efficiency while using environmentally friendly R32 refrigerant suitable for modern energy codes.

Performance:
Offering a true 17 SEER2 and EER2 around 9.4, the CH32‑12CA minimizes operating costs. The inverter-driven rotary compressor adjusts frequency to match load, reducing cycling losses. A high-efficiency heat exchanger coil provides uniform temperature distribution, and indoor airflow ranges from approximately 353 to 247 CFM across fan speeds, delivering customizable comfort profiles. It effectively maintains indoor comfort during extreme outdoor humidity and heat.

Smart Features:
This model includes Eco Smart connectivity with optional Wi-Fi module for remote temperature control and scheduling. It supports smart thermostat compatibility and popular smart home platforms. Features include Turbo Mode for rapid comfort recovery, Smart Sleep for energy savings, Auto Defrost, louver position memory, and emergency stop functionality.

Comfort & Noise:
Indoor sound levels are low, at approximately 43 dBA on high and 33 dBA on low settings. The outdoor condenser operates around 53 dBA, suitable for residential zoning. A quiet “mute” mode minimizes disturbance in bedrooms or offices. Stable airflow prevents drafts or hot spots, ensuring balanced comfort.

Use Case Fit:
Ideal for single-zone residential or light commercial applications such as bedrooms, home offices, or small retail spaces. Its 115 V power and compact design fit retrofit or accessory dwelling unit applications in southern and coastal U.S. regions prioritizing R32 refrigerant.

Value & Reliability:
Equipped with a high-efficiency rotary inverter compressor, this unit balances durability and energy savings. Designed for extended maintenance intervals, it features error code diagnostics and high-efficiency filtration to maintain indoor air quality while reducing environmental impact.

Summary Wrap-Up:
The CH32‑12CA combines high efficiency, low noise, and smart controls in a compact package ideal for residential and small commercial buyers. Its use of R32 refrigerant and strong performance make it a future-ready HVAC solution offering excellent energy savings and occupant comfort.

Key Features:

  • 17 SEER2 / HSPF2 9.5 Efficiency: Maximizes energy savings in heating and cooling.

  • Inverter Rotary Compressor: Provides fast temperature response and reduced cycling.

  • Compact Outdoor Unit: Easy to site in tight spaces.

  • Ultra-Quiet Operation: Indoor sound levels as low as 33 dBA.

  • Smart Connectivity & Turbo Mode: Enables remote control and rapid temperature adjustment.

  • High-Efficiency Air Filtration: Enhances indoor air quality.

  • Intelligent Defrost & Anti-Cold Wind: Ensures comfort during heating cycles.

White Paper

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
Comfortstar
Width:
27.56 (in)
Height:
20.08 (in)
Depth:
11.89 (in)
Weight:
53.57 LBS
Electrical Frequency:
60 Hz
Heating Output (BTU):
10,000 - 19,000 BTU
Refrigerant Type:
R-32
Product Category:
Ductless Mini Split Single Zone
Prop 65 Warning:
Yes
Electrical Phase:
1-Phase
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Configuration:
Wall Mount
Cooling Capacity (BTU):
12,000
Connection Type:
Flared
Zones:
1
AHRI Certified:
Yes
Compressor Type:
Inverter
Capacity (Tons):
1
Mount Type:
Wall Mount
System Type:
Heat Pump
SEER2:
17 SEER2
Wi-Fi Control:
Built-In
Voltage / Phase:
115V 1-Phase
Outdoor Unit CH32-12CAO - Nominal Capacity (Tons):
1
Outdoor Unit CH32-12CAO - Cooling Capacity (BTU/h):
11,500
Outdoor Unit CH32-12CAO - Heating Capacity (BTU/h):
11,500
Outdoor Unit CH32-12CAO - Refrigerant:
R-32
Outdoor Unit CH32-12CAO - Voltage/Phase/Hz:
115 V / 1 Ph / 60 Hz
Outdoor Unit CH32-12CAO - Sound Level (dB):
53
Outdoor Unit CH32-12CAO - Liquid Line Size:
1/4 in
Outdoor Unit CH32-12CAO - Suction Line Size:
3/8 in
Indoor Unit CH32-12CAI - Type:
Wall Mounted
Indoor Unit CH32-12CAI - Nominal Capacity (Tons):
1
Indoor Unit CH32-12CAI - Cooling Capacity (BTU/h):
11,500
Indoor Unit CH32-12CAI - Heating Capacity (BTU/h):
11,500
Indoor Unit CH32-12CAI - Refrigerant:
R-32
Indoor Unit CH32-12CAI - Airflow (CFM):
206-277
Indoor Unit CH32-12CAI - Sound Level (dB):
29-42.9
Indoor Unit CH32-12CAI - Liquid Line Size:
1/4 in
Indoor Unit CH32-12CAI - Suction Line Size:
3/8 in
Outdoor Unit CH32-12CAO - Unit Dimensions (W x D x H):
30.98 in x 11.41 in x 19.60 in
Outdoor Unit CH32-12CAO - Unit Weight:
46.3 lb
Outdoor Unit CH32-12CAO - Shipping Weight:
52.9 lb
Indoor Unit CH32-12CAI - Unit Dimensions (W x D x H):
30.59 in x 7.91 in x 9.84 in
Indoor Unit CH32-12CAI - Unit Weight:
16.5 lb
Indoor Unit CH32-12CAI - Shipping Weight:
20.9 lb
Sound Level Indoor (dB):
29
Minimum Heating Temp (°F):
5
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
7 Years Compressor & 5 Years Parts | Registration Required within 60 Days of Purchase
Frequently asked questions
What refrigerant does the use?
It uses R-32 refrigerant.
How much cooling does the provide?
It is rated for 12,000 BTU of cooling.
How many zones does the support?
It supports 1 zone(s).
What size is the ?
The is a 1 ton unit.
What is the SEER2 rating of the ?
The is rated at 17 SEER2 SEER2.
Can the be controlled over Wi-Fi?
Built-In.
What power supply does the need?
It requires 115V 1-Phase power.
How cold can it be outside for the to keep heating?
It is rated to heat down to 5 °F outdoors.
What warranty comes with the CH32-12CA?
7 Years Compressor & 5 Years Parts | Registration Required within 60 Days of Purchase
Who makes the CH32-12CA?
The CH32-12CA is made by Comfortstar.
