Description
Product Summary
The Daikin SkyAir RZA48AAVJU-FCA48AAVJU is a matched 48,000 BTU (4 ton) single-zone heat pump system. It pairs the RZA48AAVJU inverter outdoor unit with the FCA48AAVJU round flow ceiling cassette indoor unit, runs on 208/230V 1-Phase power and uses R-32 refrigerant.
As a matched set it carries AHRI Reference No. 217175213 and is rated at 18 SEER2 and 8.8 EER2, with 9.7 HSPF2 in heating. It keeps heating down to -4°F outdoors.
The ceiling cassette recesses into the ceiling and spreads air in several directions, which suits offices, retail spaces, restaurants and large open rooms.
What's Included
- Outdoor unit: Daikin RZA48AAVJU
- Indoor unit: Daikin FCA48AAVJU (round flow ceiling cassette indoor unit)
Line set, wiring, disconnect, mounting hardware, decoration panel and controller are sold separately.
Key Features
- Inverter compressor: variable-speed operation matches output to the load for steady comfort and lower energy use
- R-32 refrigerant: lower-GWP refrigerant used in the current Daikin single-zone lineup
- High efficiency: up to 18 SEER2 and 9.7 HSPF2
- Low ambient heating: heating operation down to -4°F
- Flexible piping: 230 ft total, 98 ft vertical maximum
- Ceiling cassette: multi-direction airflow from a flush ceiling panel
- Inverter matched system: works with the Daikin RZA48AAVJU inverter outdoor unit
- Airflow: 1,253 / 971 / 741 CFM
System Ratings
| System Model | RZA48AAVJU-FCA48AAVJU |
|---|---|
| AHRI Reference No. | 217175213 |
| Series | Daikin SkyAir |
| System Type | Single-zone inverter heat pump |
| Nominal Capacity | 48,000 BTU/h (4 ton) |
| Rated Cooling Capacity | 48,000 BTU/h |
| Rated Heating Capacity (47°F) | 54,000 BTU/h |
| SEER2 | 18 |
| EER2 | 8.8 |
| HSPF2 | 9.7 |
| Minimum Heating Operating Temp | -4°F |
| Power Supply | 208/230V 1-Phase, 60 Hz |
| Refrigerant | R-32 |
| Line Set (Liquid x Gas) | 3/8 x 5/8 in |
| Max Piping Length | 230 ft total, 98 ft vertical |
| Number of Boxes | 2 |
Outdoor Unit: RZA48AAVJU
| Model Number | RZA48AAVJU |
|---|---|
| Series | Daikin SkyAir |
| Unit Type | Single-zone outdoor unit, inverter heat pump |
| Nominal Capacity | 48,000 BTU/h (4 ton) |
| Rated Cooling Capacity | 48,000 BTU/h (with FCA48AAVJU) |
| Rated Heating Capacity (47°F) | 54,000 BTU/h |
| Heating Capacity (17°F) | 34,800 BTU/h |
| SEER2 | 18 |
| EER2 | 8.8 |
| HSPF2 | 9.7 |
| Power Supply | 208/230V 1-Phase, 60 Hz |
| Minimum Heating Operating Temp | -4°F |
| Refrigerant | R-32 |
| Line Set (Liquid x Gas) | 3/8 x 5/8 in |
| Max Piping Length | 230 ft total, 98 ft vertical |
| Unit Net Weight | 234 lb |
Indoor Unit: FCA48AAVJU
| Model Number | FCA48AAVJU |
|---|---|
| Series | Daikin SkyAir |
| Unit Type | Round Flow Ceiling Cassette indoor unit |
| Nominal Capacity | 48,000 BTU/h (4 ton) |
| System Type | Heat pump |
| Power Supply | 208/230V 1-Phase, 60 Hz |
| Airflow (CFM, H / M / L) | 1,253 / 971 / 741 |
| Refrigerant | R-32 |
| Unit Net Weight | 58 lb |
Frequently Asked Questions
What is the AHRI number for the Daikin RZA48AAVJU-FCA48AAVJU?
AHRI Reference No. 217175213. The rating applies to this exact pairing of the RZA48AAVJU outdoor unit and the FCA48AAVJU indoor unit.
What comes in the box?
Two boxes: the RZA48AAVJU outdoor unit and the FCA48AAVJU indoor unit. Line set, wiring, disconnect, mounting hardware, decoration panel and controller are sold separately.
What size room does a 48K system cover?
As a rough guide, about 2,000 to 2,400 sq ft. Insulation, ceiling height, windows and climate change that number, so ask your contractor for a load calculation.
Who should install it?
Have a licensed HVAC contractor install the system so it runs as designed and stays eligible for the Daikin warranty.
