GeoStar 4 Ton 13 EER Vertical Left Return Water Source Heat Pump Package Unit PSC Motor R454B Refrigerant 208/230V 1-Phase | ZBV048TL000CAN

GeoStar

5 Star RatingLeave a review
No reviews yet Write a Review
SKU:
ZBV048TL000CAN
Your Price $0.00
Detecting ZIP...
Est. Net Incentive Amount: $0.00
We could not detect your ZIP automatically. Enter your ZIP to check incentives.
Available Incentives
$0.00
Selected Incentives
0
Unpriced Programs
0
Estimates assume eligibility; programs and amounts can change.
Learn more about incentives
ZBV048TL000CAN GeoStar 4 Ton 13 EER Vertical Left Return Water Source Heat Pump Package Unit PSC Motor 230V 1Ph — view 1
Condition:
New
Width:
22.50 (in)
Height:
44.20 (in)
Depth:
26.20 (in)

Questions about GeoStar 4 Ton 13 EER Vertical Left Return Water Source Heat Pump Package Unit PSC Motor R454B Refrigerant 208/230V 1-Phase | ZBV048TL000CAN?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business
View Certification

Fast Shipping

Customer Support

Warranty Coverage

Financing Available

$7,086.15
10 in stock • Ships in 2-3 Business Days
Overview

GeoStar 4 Ton 13 EER Vertical Left Return Water Source Heat Pump Package Unit PSC Motor R454B Refrigerant 208/230V 1-Phase | ZBV048TL000CAN

ZBV048TL000CAN GeoStar 4 Ton 13 EER Vertical Left Return Water Source Heat Pump Package Unit PSC Motor 230V 1Ph — view 1
Product details

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
GeoStar
Width:
22.50 (in)
Height:
44.20 (in)
Depth:
26.20 (in)
Weight:
305.00 LBS
Product Type:
Water Source Heat Pump
Application:
Commercial
Blower Motor Type:
PSC
Condensate Drain:
Left
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Prop 65 Warning:
Yes
Capacity (Tons):
4
Package Type:
Water Source
Configuration:
Vertical
Electrical Phase:
1-Phase
Return Air / Filter Location:
Left Return
Voltage / Phase:
208/230V 1-Phase
Cooling Capacity (BTU):
47,200
EER | Water Loop:
13.0
Heating BTU | Water Loop:
59,000
COP | Water Loop:
4.6
EER | Ground Water:
19.8
Heating BTU | Ground Water:
48,000
COP | Ground Water:
4.0
EER | Ground Loop:
15.0
Heating BTU | Ground Loop:
36,500
COP | Ground Loop:
3.3
Airflow (CFM):
1,600
Flow (GPM):
12
Minimum Circuit Ampacity (MCA):
30.8
Maximum Overcurrent Protection (MOP):
50
Breaker Size (Amps):
50
Electrical Frequency:
60 Hz
Loop In/Out FPT:
.75”
Compressor Type:
Scroll
Refrigerant Type:
R-454B
Heat Exchanger Material:
Copper
Compressor Stages:
Single Stage
Product Line:
Arbor Compact (ZB)
AHRI Certified:
Yes
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
5 Years Compressor & 2 Years Parts | Registration Required within 60 Days of Purchase
Frequently asked questions
What size is the ?
The is a 4 ton unit.
What power supply does the need?
It requires 208/230V 1-Phase power.
How much cooling does the provide?
It is rated for 47,200 BTU of cooling.
What refrigerant does the use?
It uses R-454B refrigerant.
What warranty comes with the ZBV048TL000CAN?
5 Years Compressor & 2 Years Parts | Registration Required within 60 Days of Purchase
Who makes the ZBV048TL000CAN?
The ZBV048TL000CAN is made by GeoStar.
