Extra Information
See Your Energy Savings Instantly
Loading your personalized savings…
| System | Annual Savings |
|---|---|
| Standard (Regional Avg) | |
| Your Choice |
Based on public utility & climate data
Brand:
Goodman
Width:
14.00
(in)
Height:
34.00
(in)
Depth:
28.03
(in)
Weight:
100.00 LBS
Capacity (Tons):
2.5
Configuration:
Horizontal
Available Regions:
Nationwide - Except CA
Product Category:
Gas Heating & Air Conditioner Bundle
Safety Information:
PROP 65 WARNING: This product and other products on our site may contain a chemical known to the State of California to cause cancer or birth defects or other reproductive harm.
AHRI Certified:
Yes
Liquid Line Size | OD - Outside Diameter:
3/8
Heating BTU:
80,000
Prop 65 Warning:
Yes
Line Set Connection Type:
Solder
Prod Weight (lbs):
291
Refrigerant Type:
R32
Gas Furnace Stages:
Two Stage
Electrical Phase:
1ph
Air Flow (CFM):
1600
AFUE%:
80
AHRI Reference Number:
215214861
Vent Type:
Chimney Vent
Voltage:
208 to 230
SEER2 | Seasonal Energy Efficiency Ratio 2:
15.2
Ship Weight (lbs):
361
Brand:
Goodman
Cabinet Width (Inches):
21
Blower Motor Type:
ECM Multi-Speed
Cooling BTU | British Thermal Unit:
30,000
Color:
Gray
Electrical Frequency:
60hz
EER2 | Energy Efficiency Ratio 2:
12
Warranty Information
10 Year Heat Exchanger & 10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase
2023 Energy Standards
Department of Energy (DOE) State Regulations – Effective 2023
Click on the link below to find out more details about the energy standards for your area.
DOE State Standards Document
Click on the link below to find out more details about the energy standards for your area.
DOE State Standards Document
