Description
Product Summary
The LG APHWC501M is a 58-gallon inverter heat pump water heater for whole-house domestic hot water. It moves heat from the surrounding air into the tank with an inverter-driven compressor, and switches to its resistance elements only when demand calls for it.
It runs on a 208/240V single-phase circuit, uses R-134a refrigerant and connects to the LG ThinQ app over built-in Wi-Fi so owners can change modes and schedules remotely. It suits homeowners, builders and plumbing contractors replacing electric tank heaters.
Key Features
- Inverter heat pump: variable-speed compressor modulates output to match hot water demand.
- Multiple operating modes: Heat Pump, Turbo, Auto and Vacation modes balance efficiency and recovery.
- LG ThinQ Wi-Fi: monitor and adjust the water heater from a smartphone.
- Hybrid electric backup: upper and lower electric elements boost recovery during heavy use.
- 208/240V operation: installs on a standard dedicated 30 A water heater circuit.
Specifications
| Brand | LG |
|---|---|
| Model | APHWC501M |
| Nominal Tank Size | 58 gal (per LG spec book) |
| Voltage | 208-240V / 60 Hz / 1-Phase |
| MCA / MOP | 30.1 A / 30 A |
| Heating Elements | 3.8 kW (208V) / 5 kW (240V) upper and lower |
| Refrigerant | R-134a |
| Operating Modes | Auto, Turbo, Heat Pump, Vacation, Schedule |
| Connectivity | Built-in LG ThinQ Wi-Fi |
Ideal Applications
- Single-family homes replacing electric tank water heaters
- Garages, basements and utility rooms with adequate air volume
- New construction targeting high-efficiency water heating
- Rebate-driven heat pump water heater upgrades
Frequently Asked Questions
What circuit does it need?
It is rated 208-240V single-phase on a dedicated circuit with a 30 A breaker. Confirm local code and the installation manual.
Does it need a lot of space?
Heat pump water heaters draw heat from the room air, so install it in a space with good air volume such as a garage or basement and plan a condensate drain.
Can I control it from my phone?
Yes. Built-in Wi-Fi connects the unit to the LG ThinQ app.
What refrigerant does it use?
It uses R-134a refrigerant in a sealed factory-charged system.
