Name: Mitsubishi Electric 24,000 BTU 18 SEER2 Wall Mounted Ductless Mini Split Heat Pump System R454B Refrigerant | MZ-WX24
Brand: Mitsubishi Electric
SKU: MUZ-WX24WL-MSZ-WX24WL
Price: 2936.06 USD
Availability: InStock

Mitsubishi Electric 24,000 BTU 18 SEER2 Wall Mounted Ductless Mini Split Heat Pump System R454B Refrigerant | MZ-WX24

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Quick sizing snapshot

Enter your home size and a few basics to see a quick HVAC365 sizing snapshot you can review with a Professional.

Home size (sq ft)

Enter at least 100 sq ft.

Use conditioned square footage only; skip garages and unfinished basements.

Climate

We’ll auto-detect for U.S. visitors.

Home type

Select your home type.

Shared walls and insulation levels change the load—pick what matches your structure.

System type

Choose a system type.

Match the system to your ductwork, fuel, or preferred heat source for best comfort.

This is a sizing estimate for general guidance only. Always confirm final size, duct design, and fuel type with a Professional before purchasing equipment or pulling permits.

Brand:

Mitsubishi Electric

Width:

31.50 (in)

Height:

28.13 (in)

Depth:

11.25 (in)

Weight:

56.00 LBS

AHRI Certified:

Yes

Connection Type:

Flared

Capacity (Tons):

Configuration:

Wall Mount

Compressor Type:

Inverter

Cooling Capacity (BTU):

24,000

Product Category:

Ductless Mini Split Single Zone

Heating Output (BTU):

20,000 - 29,000 BTU

Electrical Frequency:

60 Hz

Electrical Phase:

1-Phase

Refrigerant Type:

R-454B

Prop 65 Warning:

Yes

Safety Information:

⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Zones:

Mount Type:

Wall Mount

System Type:

Heat Pump

SEER2:

18 SEER2

Voltage / Phase:

208/230V 1-Phase

Outdoor Unit MUZ-WX24WL - Nominal Capacity (Tons):

Outdoor Unit MUZ-WX24WL - Cooling Capacity (BTU/h):

22,400

Outdoor Unit MUZ-WX24WL - Heating Capacity (BTU/h):

26,000

Outdoor Unit MUZ-WX24WL - Maximum Indoor Units (Zones):

Outdoor Unit MUZ-WX24WL - Refrigerant:

R-454B

Outdoor Unit MUZ-WX24WL - Voltage/Phase/Hz:

208-230 V / 1 Ph / 60 Hz

Outdoor Unit MUZ-WX24WL - Minimum Circuit Ampacity (MCA):

16 A

Outdoor Unit MUZ-WX24WL - Maximum Overcurrent Protection (MOP):

29 A

Outdoor Unit MUZ-WX24WL - Compressor Type:

Twin Rotary

Outdoor Unit MUZ-WX24WL - Minimum Heating Temp (F):

4 F

Outdoor Unit MUZ-WX24WL - Sound Level (dB):

Outdoor Unit MUZ-WX24WL - Liquid Line Size:

1/4 in

Outdoor Unit MUZ-WX24WL - Suction Line Size:

1/2 in

Outdoor Unit MUZ-WX24WL - Unit Dimensions (W x D x H):

31.5 in x 11.25 in x 28.13 in

Indoor Unit MSZ-WX24WL - Type:

Wall Mounted

Indoor Unit MSZ-WX24WL - Nominal Capacity (Tons):

Indoor Unit MSZ-WX24WL - Cooling Capacity (BTU/h):

22,400

Indoor Unit MSZ-WX24WL - Heating Capacity (BTU/h):

26,000

Indoor Unit MSZ-WX24WL - Refrigerant:

R-454B

Indoor Unit MSZ-WX24WL - Voltage/Phase/Hz:

208-230 V / 1 Ph / 60 Hz

Indoor Unit MSZ-WX24WL - Airflow (CFM):

322-622

Indoor Unit MSZ-WX24WL - Sound Level (dB):

33-50

Indoor Unit MSZ-WX24WL - Liquid Line Size:

1/4 in

Indoor Unit MSZ-WX24WL - Suction Line Size:

1/2 in

Indoor Unit MSZ-WX24WL - Unit Dimensions (W x D x H):

36.31 in x 10.31 in x 12 in

Indoor Unit MSZ-WX24WL - Unit Weight:

28 lb

Indoor Unit MSZ-WX24WL - Shipping Weight:

32 lb

Replaces Models:

MUZ-WR24NA, MSZ-WR24NA

Warranty Information

7 Years Compressor & 5 Years Parts | Registration Required within 90 Days of Purchase

Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.
