Description
This Harvia package bundles the KIP Series 4.5kW Stainless-Steel Sauna Heater with the matching Xenio CX170 control and the right amount of sauna stones, so everything you need to fire up the sauna ships together. It is sized for sauna rooms of 100-210 cu. ft.
The Harvia 4.5kW KIP45W is a traditional wall-mounted sauna heater that uses a multi-function digital Xenio wall-mounted control panel. Its large stone capacity ensures optimal heat dispersion. The attractive polished stainless steel outer casing is durable and resists corrosion. The KIP45W is engineered for sauna rooms up to 210 cubic feet.
Package includes:
- 1 x Harvia JH45WU1UL (KIP Series 4.5kW Stainless-Steel Sauna Heater, 240V 1PH)
- 1 x Harvia CX170-U1-15-XW (Xenio CX170 U1-15 Digital Control w/Wifi for Harvia Sauna Heaters)
- 1 x Harvia AC3000 (Sauna heater stones, Split Face, 5-10cm)
Heater Specifications (JH45WU1UL):
- Capacity (kW): 4.5
- Voltage / Phase: 240V 1-Phase
- Amperage: 18.8 A
- Breaker / Line Fuse: 30A
- Room Size (cu ft): 100-210
- Stone Capacity: 44 lbs (20 kg)
- Max Temperature: 194 °F (90 °C)
- Installation Type: Wall Mount
- Color / Finish: Stainless Steel
- Material: Steel
- Unit Dimensions (W x D x H): 16" (410mm) x 11" (280mm) x 24" (600mm)
- Unit Weight: 29 lbs (13.2 kg)
- Certifications: UL
Control Specifications (CX170-U1-15-XW):
- Voltage / Phase: 240V 1-Phase
- Max Temperature: 194°F
- Max Session Time: 60 Minutes
- Installation Type: Wall-Mount or Surface Embedded
- Color / Finish: Black
- Material: Plastic
- Unit Dimensions (W x D x H): 3.4"W (86mm) x 1"D (25mm)x 4.4"H (111mm)
- Unit Weight: 0.4 lbs
- Certifications: ETL
Sauna Stones Specifications (AC3000):
- Color / Finish: Natural Stone
- Material: Natural Stone
- Unit Weight: 22 lbs
Heater Key Features:
- Wall-mounted
- Stainless steel construction
- 4.5kW
- For sauna rooms from 100 to 210 cu. ft.
- Available in 240V/1PH operation or 208V/3Ph operation
- Industrial grade, serviceable heating elements
- Exceptionally large rock capacity
- UL listed
- Direct rock-to-heating element contact
- Designed, engineered, and made in Finland
Frequently Asked Questions
What comes in the KIP Series 4.5kW Sauna Heater Package with Xenio Control?
1 x Harvia JH45WU1UL (KIP Series 4.5kW Stainless-Steel Sauna Heater, 240V 1PH); 1 x Harvia CX170-U1-15-XW (Xenio CX170 U1-15 Digital Control w/Wifi for Harvia Sauna Heaters); 1 x Harvia AC3000 (Sauna heater stones, Split Face, 5-10cm).
What size sauna is the Harvia KIP45W for?
It is rated for sauna rooms of 100-210 cu. ft. Rooms with glass walls or high ceilings may need the next size up.
What electrical service does the KIP45W need?
240V 1-phase, 18.8 A, on a 30A breaker. It must be hardwired by a licensed electrician.
What warranty comes with the KIP45W?
Harvia covers it with a 2-Year warranty (Consumer Use).
