Description
The KOHLER Anthem recessed mechanical thermostatic valve is the rough-in behind a custom shower. It mixes hot and cold water mechanically and holds the outlet temperature steady during the shower, with antiscald protection, an adjustable high-temperature limit stop and a comfort setting preset to about 104°F.
Choose the number of outlets your shower needs, from one to four. Each outlet delivers up to 7 gpm and the valve supplies up to 8 gpm total at 45 psi, with an optional restrictor that caps total flow at 1.75 gpm. Inlets are 3/4 in female NPT and outlets are 1/2 in female NPT.
The valve body is the rough-in only. Pair it with the matching KOHLER Anthem recessed push-button control panel trim for the same number of outlets, sold separately.
Key Features:
- Mechanical thermostatic mixing for steady outlet temperature
- Antiscald protection with adjustable high-temperature limit stop
- Comfort setting preset to about 104°F (40°C)
- One, two, three or four outlets
- Up to 8 gpm total, 7 gpm from any one outlet at 45 psi
- Optional 1.75 gpm flow restrictor
- 3/4 in female NPT inlets, 1/2 in female NPT outlets
- ASME A112.18.1/CSA B125.1 and ASSE 1016 certified
- Requires matching Anthem recessed control panel trim (sold separately)
Frequently Asked Questions
Does this include the trim?
No. This is the valve body only; the Anthem recessed push-button trim with the same outlet count is sold separately.
How much flow does it support?
Up to 8 gpm total at 45 psi, with a maximum of 7 gpm from any one outlet.
