LG 12,000 BTU Single Zone Heat Pump Outdoor Unit Single Zone Console / Cassette Series R32 | KUSXB121A

LG

5 Star RatingLeave a review
No reviews yet Write a Review
SKU:
KUSXB121A
Your Price $0.00
Detecting ZIP...
Est. Net Incentive Amount: $0.00
We could not detect your ZIP automatically. Enter your ZIP to check incentives.
Available Incentives
$0.00
Selected Incentives
0
Unpriced Programs
0
Estimates assume eligibility; programs and amounts can change.
Learn more about incentives
LG 12,000 BTU Single Zone Heat Pump Outdoor Unit Single Zone Console / Cassette Series R32, model KUSXB121A
Condition:
New
Width:
30.31 (in)
Height:
21.50 (in)
Depth:
13.00 (in)

Questions about LG 12,000 BTU Single Zone Heat Pump Outdoor Unit Single Zone Console / Cassette Series R32 | KUSXB121A?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business
View Certification

Fast Shipping

Customer Support

Warranty Coverage

Financing Available

$2,568.33
25 in stock • Ships in 1-2 Business Days
Overview

LG 12,000 BTU Single Zone Heat Pump Outdoor Unit Single Zone Console / Cassette Series R32 | KUSXB121A

LG 12,000 BTU Single Zone Heat Pump Outdoor Unit Single Zone Console / Cassette Series R32, model KUSXB121A
Product details

Description

Overview

The LG KUSXB121A is a 12,000 BTU class single-zone heat pump outdoor unit from the LG Single Zone Console / Cassette line. It uses R-32 refrigerant and is sold individually so it can be matched with compatible LG equipment.

Compatibility

Confirm the approved combination, line set sizes and electrical requirements against the LG submittal before ordering. Professional installation is recommended.

Warranty

7 Years Compressor & 5 Years Parts | Registration Required within 60 Days of Purchase

White Paper

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
LG
Width:
30.31 (in)
Height:
21.50 (in)
Depth:
13.00 (in)
Weight:
110.00 LBS
Prop 65 Warning:
Yes
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Product Category:
Ductless Mini Split Outdoor Unit
Product Line:
LG Single Zone Console / Cassette
Cooling Capacity (BTU):
12,000
Capacity (Tons):
1
Refrigerant Type:
R-32
System Type:
Heat Pump
Voltage / Phase:
208/230V 1-Phase
Unit Type:
Single-Zone Outdoor Unit
Cooling Capacity (BTU/h):
12,000
Rated Cooling Capacity (BTU/h):
10,200
SEER / EER (matched system):
19.7 / 13.0 (with KNUQB121A)
Voltage/Phase/Hz:
208-230 V / 1 Ph / 60 Hz
MCA / MOCP:
15 A / 13.4 A
Rated Amps Cool / Heat:
10.1 / 10.1 A
Unit Dimensions (W x D x H):
30.31 in x 13 in x 21.5 in
Liquid Line Size:
1/4 in
Vapor Line Size:
3/8 in
Compressor:
LG R1 Compressor - Twin Rotary Inverter
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
7 Years Compressor & 5 Years Parts | Registration Required within 60 Days of Purchase
Videos1 videos
LG HVAC : DUAL VANE Cassette with Air Purification | LG
Frequently asked questions
How much cooling does the provide?
It is rated for 12,000 BTU of cooling.
What size is the ?
The is a 1 ton unit.
What refrigerant does the use?
It uses R-32 refrigerant.
What power supply does the need?
It requires 208/230V 1-Phase power.
What warranty comes with the KUSXB121A?
7 Years Compressor & 5 Years Parts | Registration Required within 60 Days of Purchase
Who makes the KUSXB121A?
The KUSXB121A is made by LG.
