Description
Overview
This LG Multi F heat pump system pairs the KUMXB301A outdoor unit with 3 LG Multi F standard wall-mounted indoor units for tri-zone heating and cooling. Every indoor unit in this system is the same style, so each room gets matching appearance, airflow and controls. The system runs on 208/230V, 1-phase, 60 Hz power and uses R-32 refrigerant.
What Is Included
- 1 x KUMXB301A multi-zone outdoor unit (4 direct ports, LG R1 twin rotary inverter compressor)
- 3 x KNMAB071A (7,000 BTU LG Multi F standard wall-mounted indoor unit)
Performance
This exact non-ducted combination (7K + 7K + 7K) is listed in the LG Combination Data Manual at 22.8 SEER2, 13.8 EER2 and 9.2 HSPF2, with a rated cooling capacity of 21,000 BTU/h and a rated heating capacity of 24,300 BTU/h. Heating operation is rated down to -4 F outdoor temperature (wet bulb) and cooling operation from 14 F to 118 F.
Comfort and Noise
Each zone has its own indoor unit and set point, so occupied rooms can be conditioned independently while unused rooms stay idle. The inverter compressor adjusts its speed to match the load, which holds temperatures steadily and reduces on/off cycling.
Smart Features
These indoor units have built-in Wi-Fi for control through the LG ThinQ app. Each indoor unit includes a wireless remote controller.
Use Case Fit
Wall-mounted indoor units suit bedrooms, offices, living rooms and additions where a high wall location is available. Confirm room loads, line set lengths and electrical requirements before ordering. Professional installation is recommended.
Value and Reliability
Bundling the outdoor unit with matched indoor units in one product simplifies ordering. Warranty: 7 Years Compressor & 5 Years Parts | Registration Required within 60 Days of Purchase.
Key Features
- Tri-zone system: 7K + 7K + 7K
- 22.8 SEER2 / 9.2 HSPF2
- R-32 refrigerant
- Heating down to -4 F
- Single indoor style throughout: LG Multi F standard wall-mounted
