Rheem 10 Ton 11.2 EER Commercial Air Conditioner Split System, 460V 3-Phase, with Belt Drive VFD Commercial Air Handler, R454B | RACY2120DAZ RHCYA2120DAS

Rheem

5 Star RatingLeave a review
No reviews yet Write a Review
SKU:
RACY2120DAZ-RHCYA2120DAS
Your Price $0.00
Detecting ZIP...
Est. Net Incentive Amount: $0.00
We could not detect your ZIP automatically. Enter your ZIP to check incentives.
Available Incentives
$0.00
Selected Incentives
0
Unpriced Programs
0
Estimates assume eligibility; programs and amounts can change.
Learn more about incentives
Rheem 10 Ton 11.2 EER Commercial Air Conditioner Split System, 460V 3-Phase, with Belt Drive VFD Commercial Air Handler, R454B | RACY2120DAZ RHCYA2120DAS
Condition:
New
Width:
40.00 (in)
Height:
44.00 (in)
Depth:
74.30 (in)

Questions about Rheem 10 Ton 11.2 EER Commercial Air Conditioner Split System, 460V 3-Phase, with Belt Drive VFD Commercial Air Handler, R454B | RACY2120DAZ RHCYA2120DAS?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business
View Certification

Fast Shipping

Customer Support

Warranty Coverage

Financing Available

$28,836.27
  • Qualifies for FREE Shipping
5 in stock • Ships in 1-2 Business Days
Overview

Rheem 10 Ton 11.2 EER Commercial Air Conditioner Split System, 460V 3-Phase, with Belt Drive VFD Commercial Air Handler, R454B | RACY2120DAZ RHCYA2120DAS

Rheem 10 Ton 11.2 EER Commercial Air Conditioner Split System, 460V 3-Phase, with Belt Drive VFD Commercial Air Handler, R454B | RACY2120DAZ RHCYA2120DAS
Product details

Description

Rheem 10 Ton Commercial Air Conditioner Split System (RACY2120DAZ + RHCYA2120DAS)

This AHRI-certified Rheem split system pairs the RACY2120DAZ Commercial Classic Series RACY condensing unit with the RHCYA2120DAS belt-drive commercial air handler. Both run on 460 volt 3-phase power. It is a 10 ton cooling system for offices, retail, restaurants, schools and light industrial space where the air handler sits in a mechanical room, mezzanine or above-ceiling platform and the condenser sits on a pad or roof.

The system is cooling only. Electric heat can be added inside the air handler with a Rheem RXHE heater kit offered on this listing.

System performance

  • AHRI reference number: 214437941
  • Rated cooling capacity: 114,000 BTU/h (AHRI 340/360)
  • Efficiency: 11.2 EER, 14.8 IEER
  • Staging: Two stages of cooling for part-load operation
  • Refrigerant: R-454B (A2L)

Condenser: RACY2120DAZ

  • Compressor: 1 scroll, 2-stage
  • Power supply: 460V 3-Phase, 60 Hz
  • Minimum circuit ampacity: 24 A
  • Maximum overcurrent protection: 35 A
  • Compressor amps: RLA 14 A, LRA 123 A
  • Sound rating: 88 dB (AHRI 270)
  • Dimensions: 40.0 in W x 74.25 in D x 44.0 in H
  • Operating / shipping weight: 565 lb / 585 lb

Air handler: RHCYA2120DAS

  • Blower: Belt Drive with VFD, 2 HP, adjustable belt drive, medium static
  • Airflow: 3100-5100 CFM
  • Coil: 4 rows / 15 FPI / 10.2 sq ft
  • Metering: TXV, field adjustable, non-bleed
  • Configuration: Field convertible, vertical upflow or horizontal sideflow
  • Power supply: 460V 3-Phase, 60 Hz
  • Minimum circuit ampacity: 4 A (blower only)
  • Refrigerant connections: 5/8 in liquid / 1-3/8 in vapor
  • Filters: 1 x 16x25 or 2 x 16x25 in (filter rack accessory)
  • Dimensions: 54.5 in W x 27.86 in H x 57.85 in L
  • Operating / shipping weight: 409 lb / 429 lb

Electric heat options

Rheem RXHE auxiliary heater kits approved for the RHCYA2120DAS: RXHE-DE020DA (20.2 kW at 460V), RXHE-DE030DA (29.7 kW at 460V). Choose one in the "Add an Electric Heat Strip" option; the kit is sold separately and is not included in the system price. Air handler circuit sizing changes with the heater installed.

White Paper

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
Rheem
Width:
40.00 (in)
Height:
44.00 (in)
Depth:
74.30 (in)
Weight:
1,014.00 LBS
AHRI Certified:
Yes
AHRI Reference Number:
214437941
Refrigerant Type:
R-454B
Capacity (Tons):
10
Cooling Capacity (BTU):
114,000
EER:
11 EER
IEER:
14 IEER
Product Category:
Air Conditioner Split System
Product Line:
RACY / RHCYA
Outdoor Unit Model:
RACY2120DAZ
Air Handler Model:
RHCYA2120DAS
Voltage / Phase:
460V 3-Phase
Electrical Phase:
3-Phase
Compatible Electric Heat Kits:
RXHE-DE020DA (20.2 kW at 460V), RXHE-DE030DA (29.7 kW at 460V)
Electric Heat Options (kW):
20, 30
Outdoor Unit RACY2120DAZ - UPC:
662021686344
Outdoor Unit RHCYA2120DAS - UPC:
662021686658
Condenser RACY2120DAZ - Nominal Capacity (Tons):
10
Condenser RACY2120DAZ - Refrigerant:
R-454B
Condenser RACY2120DAZ - Voltage/Phase/Hz:
460V 3-Phase / 60 Hz
Condenser RACY2120DAZ - Minimum Circuit Ampacity (MCA):
24 A
Condenser RACY2120DAZ - Maximum Overcurrent Protection (MOP):
35 A
Condenser RACY2120DAZ - Compressor Type:
Scroll
Condenser RACY2120DAZ - Sound Level (dB):
88
Condenser RACY2120DAZ - Unit Dimensions:
40.0 in W x 74.25 in D x 44.0 in H
Condenser RACY2120DAZ - Shipping Weight:
585 lb
Air Handler RHCYA2120DAS - Nominal Capacity (Tons):
10
Air Handler RHCYA2120DAS - Airflow (CFM):
3100-5100
Air Handler RHCYA2120DAS - Blower Motor Type:
Belt Drive with VFD, 2 HP
Air Handler RHCYA2120DAS - Configuration:
Convertible (Vertical Upflow / Horizontal)
Air Handler RHCYA2120DAS - Metering Device:
TXV
Air Handler RHCYA2120DAS - Voltage/Phase/Hz:
460V 3-Phase / 60 Hz
Air Handler RHCYA2120DAS - Minimum Circuit Ampacity (MCA):
4 A (blower only)
Air Handler RHCYA2120DAS - Liquid Line Size:
5/8 in
Air Handler RHCYA2120DAS - Suction Line Size:
1-3/8 in
Air Handler RHCYA2120DAS - Unit Dimensions:
54.5 in W x 27.86 in H x 57.85 in L
Air Handler RHCYA2120DAS - Shipping Weight:
429 lb
Prop 65 Warning:
Yes
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Warranty Information:
5 Years Compressor & 1 Year Parts
DOE Regional Compliance:
Nationwide
Electrical Frequency:
60 Hz
Air Handler RHCYA2120DAS - UPC:
662021686658
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase
Videos1 videos
Rheem Commercial: Extremely Tested. Extremely Tough.
Frequently asked questions
Is the AHRI certified?
Yes. The AHRI reference number is 214437941.
What refrigerant does the use?
It uses R-454B refrigerant.
What size is the ?
The is a 10 ton unit.
How much cooling does the provide?
It is rated for 114,000 BTU of cooling.
What power supply does the need?
It requires 460V 3-Phase power.
What warranty comes with the RACY2120DAZ-RHCYA2120DAS?
10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase
Who makes the RACY2120DAZ-RHCYA2120DAS?
The RACY2120DAZ-RHCYA2120DAS is made by Rheem.
