Name: Supco 90343 Switching Relay 24V
Brand: Supco
SKU: 90343
Price: 48.84 USD
Availability: InStock

Supco 90343 Switching Relay 24V

Description

Product Summary

The Supco 90343 Switching Relay 24V is a professional-grade replacement part from Supco (Sealed Unit Parts Co.), a trusted name in HVAC/R and appliance parts since 1945. The 90343 Relay is DPDT (double pole, double throw) with a 24VAC control coil. It provides general purpose switching for refrigeration and air conditioning equipment and appliances.

Relays and start devices control when motors, compressors, and auxiliary loads energize. This group covers general-purpose fan relays, switching relays, potential (start) relays, time-delay relays, and combination relay/capacitor/overload start kits used on HVAC and refrigeration compressors.

Key Features

General purpose switching relays DPDT contacts
WARNING: Prop 65 info

Specifications

Brand	Supco
Part Number	90343
Part Type	Relay / Start Device
Amperage @ 277V	8 FLA / 48 LRA
Amperage @ 480V	3 FLA / 18 LRA
Amperage @ 600V	3 FLA / 14 LRA

What's Included

(1) Supco 90343 Switching Relay 24V

Safety: Always disconnect power and follow lockout/tagout procedures before servicing electrical components. Installation should be performed by a qualified technician.

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Quick sizing snapshot

Enter your home size and a few basics to see a quick HVAC365 sizing snapshot you can review with a Professional.

Home size (sq ft)

Enter at least 100 sq ft.

Use conditioned square footage only; skip garages and unfinished basements.

Climate

We’ll auto-detect for U.S. visitors.

Home type

Select your home type.

Shared walls and insulation levels change the load—pick what matches your structure.

System type

Choose a system type.

Match the system to your ductwork, fuel, or preferred heat source for best comfort.

This is a sizing estimate for general guidance only. Always confirm final size, duct design, and fuel type with a Professional before purchasing equipment or pulling permits.

Brand:

Supco

Weight:

1.00 LBS

Safety Information:

⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Prop 65 Warning:

Yes

Part Type:

Relay / Start Device

Amperage @ 277V:

8 FLA / 48 LRA

Amperage @ 480V:

3 FLA / 18 LRA

Amperage @ 600V:

3 FLA / 14 LRA

Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.
