Name: Supco IDVMSPLITTER Supco® Techlink™ Line Splitter
Brand: Supco
SKU: IDVMSPLITTER
Price: 61.4 USD
Availability: InStock

Supco IDVMSPLITTER Supco® Techlink™ Line Splitter

Description

Product Summary

The Supco IDVMSPLITTER Supco® Techlink™ Line Splitter is a professional-grade replacement part from Supco (Sealed Unit Parts Co.), a trusted name in HVAC/R and appliance parts since 1945. IDVMSPLITTER is an AC Line Splitter used to separate the hot from the neutral (and ground) conductors for safe and accurate amperage measurements without the need to cut the power cord. It is a great accessory to use with our App-Connected meters.

Multimeters, megohmmeters, and current probes for diagnosing HVAC/R electrical circuits, motors, and compressors.

Key Features

Easy & safe AC measurements with a clamp meter without the need to cut or separate conductors
Multimeter and iDVM333 Amp Clamp for easy power calculations
Separate the hot/live conductor from the neutral and ground
Use with the iDVM550 Clamp Meter or the iDVM510
X1 loop for one-to-one amperage readings
X10 multiplier loop for higher resolution and accuracy for low power circuits

Specifications

Brand	Supco
Part Number	IDVMSPLITTER
Part Type	Meter
Size	6-1/4" x 2-1/4"x 1-1/4"
Weight	5.6 oz.
Voltage	250 VAC Max.
Current	15 Amps. Max.
Frequency	50/60 Hz.

Related Parts

Commonly used with: Supco IDVM550, Supco F600MA, Supco FF10A.

What's Included

(1) Supco IDVMSPLITTER Supco® Techlink™ Line Splitter

Safety: Always disconnect power and follow lockout/tagout procedures before servicing electrical components. Installation should be performed by a qualified technician.
