Description
Product Summary
The Supco LBK10 Linebacker® Surge Protector is a professional-grade replacement part from Supco (Sealed Unit Parts Co.), a trusted name in HVAC/R and appliance parts since 1945. The LBK10 uses state-of-the-art TPMOV technology coupled with the ability to remove your equipment from damaging surges, the LBK10 provides the ultimate solution for you surge protection needs.
Surge protectors shield compressors, control boards, and appliances from voltage spikes, lightning, and utility switching surges that cause premature electronic and motor failures.
Key Features
- 3 Year Connected equipment guarantee
- 3 Year product warranty
- 4X style Weatherproof housing
- Easy installation at condensing unit
- Green LED indicates surge protection status
- Ground Monitor
- NO/NC relay to disconnect equipment and/or activate indicator
- See product sheet F582 in 'Downloads' section for more information
- TPMOV Technology
- Type 2 Surge Protection Device
- UL® Listed 1449, 4th edition
- Voltage Monitor
Specifications
| Brand | Supco |
|---|---|
| Part Number | LBK10 |
| Part Type | Surge Protector |
| Voltage | 120/240 VAC |
| Frequency | 50/60 Hz |
| Nominal Discharge Current (IN) | 10 kA |
| Short Circuit Current Rating (SCCR) | 10 kA |
| Relay Contact Rating | 12A @ 250 VAC |
| Under/Over Voltage Per Phase | 100V to 138V |
Frequently Asked Questions
Does this protect the whole house?
No.
White Paper
- Supco LBK10 Product Specification Sheet (PDF)
- Supco LBK10 Installation & Operation Manual (PDF)
- Supco LBK10 Application Sheet (PDF)
What's Included
- (1) Supco LBK10 Linebacker® Surge Protector
Safety: Always disconnect power and follow lockout/tagout procedures before servicing electrical components. Installation should be performed by a qualified technician.
