Supco 4 'n 1 Hard Start 1/12-1/5 HP | URCO810RC

Name: Supco 4 'n 1 Hard Start 1/12-1/5 HP | URCO810RC
Brand: Supco
SKU: URCO810RC
Price: 28.87 USD
Availability: InStock

Supco

5 Star RatingLeave a review

No reviews yet Write a Review

SKU:: URCO810RC

Your Price $0.00

Detecting ZIP...

Est. Net Incentive Amount: $0.00

We could not detect your ZIP automatically. Enter your ZIP to check incentives.

Available Incentives

$0.00

Selected Incentives

Unpriced Programs

Estimates assume eligibility; programs and amounts can change.

Learn more about incentives

Supco URCO810RC 4 'n 1 Hard Start 1/12-1/5 HP

UPC:
Condition:: New
Width:: 5.00 (in)
Height:: 3.00 (in)
Depth:: 4.00 (in)

Questions about Supco 4 'n 1 Hard Start 1/12-1/5 HP | URCO810RC?

SupplierGateway® Certified i

Minority-Owned • Small Business

View Certification

Fast Shipping

Customer Support

Warranty Coverage

Financing Available

$28.87

Overview

Supco 4 'n 1 Hard Start 1/12-1/5 HP | URCO810RC

Product details

Description

Product Summary

The Supco URCO810RC 4 'n 1 Hard Start 1/12-1/5 HP is a professional-grade replacement part from Supco (Sealed Unit Parts Co.), a trusted name in HVAC/R and appliance parts since 1945. 110 to 125 VAC Solid-state Hardstart Relay, includes relay, overload, start and run capacitor. Used on refrigeration systems without run capacitors. Rated for 1/12 HP to 1/5 HP compressors. Maximum RLA 4.05 Amps. This kit includes a new run capacitor.

Relays and start devices control when motors, compressors, and auxiliary loads energize. This group covers general-purpose fan relays, switching relays, potential (start) relays, time-delay relays, and combination relay/capacitor/overload start kits used on HVAC and refrigeration compressors.

Key Features

Designed for modern high efficiency compressors
Easy mount clip for quick installation
Helps older compressors start and run cooler
Ideal solution for replacing all four components in a system with a run capacitor
Prevents low voltage starting problems
Wire Designations - White/Start, Black/Common, Red/Run
WARNING: Prop 65 info

Specifications

Brand	Supco
Part Number	URCO810RC
Part Type	Relay / Start Device
Mounting	Push-on
HP rating	1/12 - 1/5 hp
Voltage (VAC)	115
Run capacitor	12.5 uF
Maximum Continuous RLA	4.05A
Capacitance	145 to 175 MFD

Frequently Asked Questions

What size 3 in 1 should I choose?
Sizing is based on the HP rating of the compressor, and the continuous running amperage.

What is the difference between the RCO and URCO series?
The URCO has an additional set of leads to accommodate a run capacitor.

White Paper

What's Included

(1) Supco URCO810RC 4 'n 1 Hard Start 1/12-1/5 HP

Safety: Always disconnect power and follow lockout/tagout procedures before servicing electrical components. Installation should be performed by a qualified technician.

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Quick sizing snapshot

Enter your home size and a few basics to see a quick HVAC365 sizing snapshot you can review with a Professional.

Home size (sq ft)

Enter at least 100 sq ft.

Use conditioned square footage only; skip garages and unfinished basements.

Climate

We’ll auto-detect for U.S. visitors.

Home type

Select your home type.

Shared walls and insulation levels change the load—pick what matches your structure.

System type

Choose a system type.

Match the system to your ductwork, fuel, or preferred heat source for best comfort.

This is a sizing estimate for general guidance only. Always confirm final size, duct design, and fuel type with a Professional before purchasing equipment or pulling permits.

Brand:

Supco

Width:

5.00 (in)

Height:

3.00 (in)

Depth:

4.00 (in)

Weight:

1.00 LBS

Safety Information:

⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Prop 65 Warning:

Yes

Part Type:

Relay / Start Device

Mounting:

Push-on

HP rating:

1/12 - 1/5 hp

Voltage (VAC):

115

Run capacitor:

12.5 uF

Maximum Continuous RLA:

4.05A

Capacitance:

145 to 175 MFD

Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.
