AireVantage 3 Ton 14.3 Seer Air Conditioner Split System R454B Refrigerant | USA4BE5M1SN36K-B65BMMX36K-B

AireVantage

5 Star RatingLeave a review
No reviews yet Write a Review
SKU:
USA4BE5M1SN36K-B65BMMX36K-B
Your Price $0.00
Detecting ZIP...
Est. Net Incentive Amount: $0.00
We could not detect your ZIP automatically. Enter your ZIP to check incentives.
Available Incentives
$0.00
Selected Incentives
0
Unpriced Programs
0
Estimates assume eligibility; programs and amounts can change.
Learn more about incentives
AireVantage 3 Ton 14.3 Seer Air Conditioner Split System R454B Refrigerant, model USA4BE5M1SN36K-B65BMMX36K-B
Condition:
New
Width:
31.75 (in)
Height:
41.00 (in)
Depth:
31.75 (in)

Questions about AireVantage 3 Ton 14.3 Seer Air Conditioner Split System R454B Refrigerant | USA4BE5M1SN36K-B65BMMX36K-B?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business
View Certification

Fast Shipping

Customer Support

Warranty Coverage

Financing Available

$3,754.05
55 in stock • Ships in 1-2 Business Days
Overview

AireVantage 3 Ton 14.3 Seer Air Conditioner Split System R454B Refrigerant | USA4BE5M1SN36K-B65BMMX36K-B

AireVantage 3 Ton 14.3 Seer Air Conditioner Split System R454B Refrigerant, model USA4BE5M1SN36K-B65BMMX36K-B
Product details

Description

The AireVantage 3 Ton 14.3 SEER2 Air Conditioner Split System with R-454B Refrigerant (USA4BE5M1SN36K-B65BMMX36K-B) is a residential split-system air conditioner designed to provide reliable cooling for compatible HVAC applications. The matched system combines the USA4BE5M1SN36K outdoor condenser with the B65BMMX36K-B multi-position air handler and is rated at 14.3 SEER2 and 11.7 EER2.

The outdoor unit features a Copeland Scroll compressor, PSC condenser fan motor, all-aluminum coil, high-pressure switch, and included liquid-line filter drier. The B65BMMX36K-B air handler has a multi-position configuration and R-454B TXV metering device for the compatible system.

Key Features

  • 3 Ton Capacity – Designed for residential cooling applications
  • 14.3 SEER2 Efficiency – Provides efficient seasonal cooling performance
  • R-454B Refrigerant – Uses lower-GWP A2L refrigerant technology
  • 36,000 BTU Nominal Capacity – Designed for 3-ton cooling applications
  • Copeland Scroll Compressor – Designed for dependable compressor operation
  • Multi-Position Air Handler – Provides flexible installation configurations
  • R-454B TXV – Designed for proper refrigerant metering
  • PSC Motor – Provides reliable blower operation

Benefits

  • Provides reliable residential cooling
  • Offers 3-ton nominal cooling capacity
  • Delivers 14.3 SEER2 efficiency
  • Uses R-454B refrigerant technology
  • Combines an outdoor condenser with a compatible multi-position air handler
  • Offers flexible air-handler installation configurations
  • Uses a scroll compressor for dependable operation
  • Includes system protection and service-friendly features

Compatibility & Installation

The USA4BE5M1SN36K-B65BMMX36K-B is a matched AireVantage split-system configuration. Gemaire's published matchup data lists the combination at 35,000 BTU cooling capacity at 95°F, 11.7 EER2, and 14.3 SEER2.

Installation considerations:

  • Verify the 3-ton system size is appropriate for the application
  • Confirm the outdoor condenser and indoor air handler are the intended matched combination
  • Verify electrical and refrigerant-line requirements
  • Follow applicable R-454B/A2L installation and safety requirements
  • Confirm proper airflow and ductwork configuration
  • Follow manufacturer installation instructions and local codes
  • Installation should be completed by a qualified HVAC professional

Frequently Asked Questions

What size is the AireVantage USA4BE5M1SN36K-B65BMMX36K-B?
It is a 3-ton split-system air conditioner with a nominal 36,000 BTU capacity. The published matched-system data lists approximately 35,000 BTU at 95°F.

What is the SEER2 rating?
The matched system is rated at 14.3 SEER2.

What refrigerant does this system use?
The system uses R-454B refrigerant.

Does this system provide heating?
No. The USA4BE5M1SN36K is a straight-cool air conditioner condenser, so this combination is designed for cooling operation.

What indoor air handler is included?
The matched indoor unit is the B65BMMX36K-B 3-ton multi-position air handler

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
AireVantage
Width:
31.75 (in)
Height:
41.00 (in)
Depth:
31.75 (in)
Weight:
195.00 LBS
SEER2:
14 SEER2
EER2:
11 EER2
Capacity (Tons):
3
Cooling Capacity (BTU):
36,000
EER:
11.2
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Prop 65 Warning:
Yes
Refrigerant Type:
R-454B
Compressor Stages:
Single Stage
DOE Regional Compliance:
Nationwide
Electrical Phase:
1-Phase
Voltage / Phase:
208/230V 1-Phase
Condenser USA4BE5M1SN36K - Nominal Capacity (Tons):
3
Condenser USA4BE5M1SN36K - Cooling Capacity (BTU/h):
36,000
Condenser USA4BE5M1SN36K - Refrigerant:
R-454B
Condenser USA4BE5M1SN36K - Voltage/Phase/Hz:
208-230 V / 1 Ph / 60 Hz
Condenser USA4BE5M1SN36K - Minimum Circuit Ampacity (MCA):
17.9 A
Condenser USA4BE5M1SN36K - Maximum Overcurrent Protection (MOP):
30 A
Condenser USA4BE5M1SN36K - Compressor Type:
Scroll
Condenser USA4BE5M1SN36K - Compressor Stages:
Single Stage
Condenser USA4BE5M1SN36K - Liquid Line Size:
3/8 in
Condenser USA4BE5M1SN36K - Sound Level (dB):
71
Air Handler B65BMMX36K-B - Nominal Capacity (Tons):
3
Air Handler B65BMMX36K-B - Configuration:
Multi-Position
Air Handler B65BMMX36K-B - Refrigerant:
R-454B
Configuration:
Multi-Position
Energy Star Listed:
No
Outdoor Model:
USA4BE5M1SN36K
Indoor Model:
B65BMMX36K-B
Product Category:
Air Conditioner Split System
Nominal Capacity:
3 Ton
Nominal Cooling Capacity:
36,000 BTU
Compressor Type:
Copeland Scroll
Metering Device:
R-454B TXV
Phase:
Single Phase
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase
Frequently asked questions
What is the SEER2 rating of the ?
The is rated at 14 SEER2 SEER2.
What size is the ?
The is a 3 ton unit.
How much cooling does the provide?
It is rated for 36,000 BTU of cooling.
What refrigerant does the use?
It uses R-454B refrigerant.
What power supply does the need?
It requires 208/230V 1-Phase power.
What warranty comes with the USA4BE5M1SN36K-B65BMMX36K-B?
10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase
Who makes the USA4BE5M1SN36K-B65BMMX36K-B?
The USA4BE5M1SN36K-B65BMMX36K-B is made by AireVantage.
