Description
Product Summary
The Bohn BEL0205BY6EEAG0212 is a 20,500 BTU/h nominal low profile walk-in unit cooler from the Bohn BEL Low Profile series, built for walk-in freezers (and coolers) in restaurants, convenience stores, grocery and food service. It uses electric defrost, 4 fan 1-Speed EC fan motors and a 6 FPI coil, and runs on 208/230V 1-Phase power.
Heatcraft rates this model at 19,500 BTU/h with R-454A (10°F TD, -20°F SST), moving 2,562 CFM. It is approved for R-454A (A2L and HFC) and ships with option package G0212 (A2L base package with factory refrigerant detection system (RDS) and intelliGen controller).
Key Features
- Low Profile design: Low-height cabinet saves headroom in walk-in boxes.
- Electric Defrost: Factory electric defrost heaters for reliable defrost in freezer duty.
- 1-Speed EC fan motors: Energy-efficient EC motors reduce operating cost.
- 6 FPI coil: Fin spacing selected for the temperature application and defrost performance.
- Refrigerant flexibility: Rated for R-454A.
- Factory configuration: A2L base package with factory refrigerant detection system (RDS) and intelliGen controller.
- A2L ready: Designed and listed for lower-GWP A2L refrigerants R-454A, R-454C and R-455A.
Specifications
| Brand | Bohn |
|---|---|
| Model | BEL0205BY6EEAG0212 |
| Series | BEL Low Profile |
| Product Type | Low Profile Unit Cooler |
| Nominal Capacity (model designation) | 20,500 BTU/h |
| Capacity, R-454A (10°F TD, -20°F SST) | 19,500 BTU/h |
| Application | Freezer / low temp |
| Defrost Type | Electric Defrost |
| Fan Motor | 1-Speed EC (1/20 HP each) |
| Number of Fans | 4 |
| Airflow | 2,562 CFM |
| Fins Per Inch | 6 |
| Voltage | 208-230/1/60 |
| Unit MCA | 2.1 A |
| Unit MOPD | 15 A |
| Defrost Heater | 4,200 W |
| Factory Option Package | G0212 (A2L base package with factory refrigerant detection system (RDS) and intelliGen controller) |
| Dimensions (H x D x L) | 16.4375 x 13.25 x 77.5 in |
| Estimated Net Weight | 100 lb |
Ideal Applications
- Walk-in freezers
- Ice cream and frozen food storage
- Restaurant and commercial kitchen freezers
- Convenience store and grocery back rooms
- Schools, hospitals and institutional food service
Frequently Asked Questions
What refrigerants can the BEL0205BY6EEAG0212 use?
Heatcraft lists it for R-454A. Confirm the refrigerant matches your condensing unit and the expansion valve selected.
What voltage does the BEL0205BY6EEAG0212 require?
This unit cooler is wired for 208/230V 1-Phase (voltage code B). Provide a dedicated circuit sized to the nameplate MCA and MOPD.
Is the BEL0205BY6EEAG0212 for a cooler or a freezer?
It has electric defrost and is rated for freezer (low temp) duty; electric defrost models can also serve coolers.
What condensing unit matches this evaporator?
Match the condensing unit capacity to the evaporator at your design suction temperature. Bohn BCH low temp condensing units are a common pairing; HVAC365 can help size the system.
What is included?
The unit cooler ships with option package G0212 (A2L base package with factory refrigerant detection system (RDS) and intelliGen controller). Expansion valve, solenoid and controls are field supplied unless the option package includes them.
