Description
Product Summary
The Bohn BEL0295BY6AMAB0000 is a 29,500 BTU/h nominal low profile walk-in unit cooler from the Bohn BEL Low Profile series, built for walk-in coolers in restaurants, convenience stores, grocery and food service. It uses air defrost, 5 fan 2-Speed EC fan motors and a 6 FPI coil, and runs on 208/230V 1-Phase power.
Heatcraft rates this model at 31,000 BTU/h with R-454A (10°F TD, 25°F SST), moving 3,050 CFM. It is approved for R-454A, R-454C, R-455A (A2L and HFC) and ships with option package B0000 (standard base configuration).
Key Features
- Low Profile design: Low-height cabinet saves headroom in walk-in boxes.
- Air Defrost: Off-cycle air defrost for coolers above freezing.
- 2-Speed EC fan motors: Energy-efficient EC motors reduce operating cost.
- 6 FPI coil: Fin spacing selected for the temperature application and defrost performance.
- Refrigerant flexibility: Rated for R-454A, R-454C, R-455A.
- Factory configuration: Standard base configuration.
- A2L ready: Designed and listed for lower-GWP A2L refrigerants R-454A, R-454C and R-455A.
Specifications
| Brand | Bohn |
|---|---|
| Model | BEL0295BY6AMAB0000 |
| Series | BEL Low Profile |
| Product Type | Low Profile Unit Cooler |
| Nominal Capacity (model designation) | 29,500 BTU/h |
| Capacity, R-454A (10°F TD, 25°F SST) | 31,000 BTU/h |
| Capacity, R-454C (10°F TD, 25°F SST) | 25,500 BTU/h |
| Capacity, R-455A (10°F TD, 25°F SST) | 33,200 BTU/h |
| Application | Cooler / medium temp |
| Defrost Type | Air Defrost |
| Fan Motor | 2-Speed EC (1/20 HP each) |
| Number of Fans | 5 |
| Airflow | 3,050 CFM |
| Fins Per Inch | 6 |
| Voltage | 208-230/1/60 |
| Unit MCA | 2.6 A |
| Unit MOPD | 15 A |
| Factory Option Package | B0000 (standard base configuration) |
| Dimensions (H x D x L) | 16.4375 x 13.25 x 93.5 in |
| Estimated Net Weight | 115 lb |
Ideal Applications
- Walk-in coolers
- Restaurant and commercial kitchen coolers
- Floral and produce coolers
- Convenience store and grocery back rooms
- Beverage and dairy storage
Frequently Asked Questions
What refrigerants can the BEL0295BY6AMAB0000 use?
Heatcraft lists it for R-454A, R-454C, R-455A. Confirm the refrigerant matches your condensing unit and the expansion valve selected.
What voltage does the BEL0295BY6AMAB0000 require?
This unit cooler is wired for 208/230V 1-Phase (voltage code B). Provide a dedicated circuit sized to the nameplate MCA and MOPD.
Is the BEL0295BY6AMAB0000 for a cooler or a freezer?
It is an air-defrost unit for coolers held above about 34°F; it is not for freezer duty.
What condensing unit matches this evaporator?
Match the condensing unit capacity to the evaporator at your design suction temperature. Bohn BCH medium temp condensing units are a common pairing; HVAC365 can help size the system.
What is included?
The unit cooler ships with option package B0000 (standard base configuration). Expansion valve, solenoid and controls are field supplied unless the option package includes them.
