Description
Product Summary
The Bohn VAK06AG is a 600 BTU/h nominal v-profile reach-in unit cooler from the Bohn VA V-Profile Reach-In series, used as the evaporator in reach-in refrigerators, back bars, under-counter cabinets and display fixtures. It features air defrost, 1 shaded pole fan motor, a protective coil coating and 115V 1-Phase power.
Heatcraft rates the VAK06AG at 600 BTU/h (10°F TD) with 135 CFM of airflow. Its compact cabinet fits tight fixture spaces where a walk-in unit cooler will not.
Key Features
- Compact reach-in design: Low-height cabinet fits inside reach-in and under-counter fixtures.
- Air Defrost: Off-cycle air defrost for fixtures held above freezing.
- Shaded pole fan motors: Simple, proven motors with 115V or 208-230V supply per model.
- Factory-wired: Ready for field connection of power, liquid and suction lines.
- Coated coil: Coil coating adds corrosion protection in harsh environments.
Specifications
| Brand | Bohn |
|---|---|
| Model | VAK06AG |
| Series | VA V-Profile Reach-In |
| Product Type | V-Profile Reach-In Unit Cooler |
| Nominal Capacity (model designation) | 600 BTU/h |
| Rated Capacity (10°F TD, HFC) | 600 BTU/h |
| Airflow | 135 CFM |
| Number of Fans | 1 |
| Fan Motor | Shaded pole |
| Amps | 0.8 A |
| Defrost Type | Air Defrost |
| Voltage | 115/1/60 |
| Coil Coating | Coated |
| Dimensions (H x D x L) | 6.875 x 8.25 x 12.5 in |
| Estimated Net Weight | 9 lb |
Ideal Applications
- Reach-in refrigerators
- Back bar and under-counter cabinets
- Display cases and merchandisers
- Bars, restaurants and convenience stores
- Deli and beverage fixtures
Frequently Asked Questions
What is the capacity of the VAK06AG?
The model designation is 600 BTU/h nominal; Heatcraft rates it at 600 BTU/h at 10°F TD.
What voltage does the VAK06AG use?
It is wired for 115V 1-Phase.
Can it be used for a freezer?
No. It is an air defrost model for fixtures held above freezing; choose an electric defrost reach-in for freezers.
What refrigerants are supported?
Heatcraft lists HFC refrigerant ratings for this reach-in coil. Confirm compatibility with your condensing unit and metering device.
Is a metering device included?
Expansion valve and controls are typically field supplied; HVAC365 can help select matching components.
