  • Cooper & Hunter Slim Duct 36,000 BTU Slim Ducted Ductless Mini Split Indoor Unit R-454B 208/230V with Wi-Fi | CH-RS36LCDT-HS

Cooper & Hunter Slim Duct 36,000 BTU Slim Ducted Ductless Mini Split Indoor Unit R-454B 208/230V with Wi-Fi | CH-RS36LCDT-HS

Cooper & Hunter

5 Star RatingLeave a review
No reviews yet Write a Review
SKU:
CH-RS36LCDT-HS
Your Price $0.00
Detecting ZIP...
Est. Net Incentive Amount: $0.00
We could not detect your ZIP automatically. Enter your ZIP to check incentives.
Available Incentives
$0.00
Selected Incentives
0
Unpriced Programs
0
Estimates assume eligibility; programs and amounts can change.
Learn more about incentives
Cooper & Hunter Slim Duct 36,000 BTU Slim Ducted Ductless Mini Split Indoor Unit R-454B 208/230V, model CH-RS36LCDT-HS
Condition:
New
Width:
47.20 (in)
Height:
11.80 (in)
Depth:
29.50 (in)

Questions about Cooper & Hunter Slim Duct 36,000 BTU Slim Ducted Ductless Mini Split Indoor Unit R-454B 208/230V with Wi-Fi | CH-RS36LCDT-HS?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business
View Certification

Fast Shipping

Customer Support

Warranty Coverage

Financing Available

$3,422.22
  • Qualifies for FREE Shipping
in stock • Special Order – Lead Time Confirmed After Order
Overview

Cooper & Hunter Slim Duct 36,000 BTU Slim Ducted Ductless Mini Split Indoor Unit R-454B 208/230V with Wi-Fi | CH-RS36LCDT-HS

Cooper & Hunter Slim Duct 36,000 BTU Slim Ducted Ductless Mini Split Indoor Unit R-454B 208/230V, model CH-RS36LCDT-HS
Product details

Description

The Cooper & Hunter CH-RS36LCDT-HS is the Slim Duct slim ducted indoor unit sold on its own, for replacing an existing head or building a system with a compatible Cooper & Hunter outdoor unit. The Slim Duct is a concealed, low-profile ducted air handler that hides above a ceiling or in a soffit and serves one or more rooms through short duct runs. Medium-static models (6-18K) handle up to 0.4 in. W.C.; high-static models (24K and up) handle up to 0.8 in. W.C. The 6-12K model is set to 6K, 9K or 12K by dip switch.

Specifications

  • Model: CH-RS36LCDT-HS
  • Cooling Capacity (BTU/h): 36,000
  • Refrigerant Piping (Liquid/Gas): 3/8"/3/4"
  • Airflow (CFM, high to low): 1,236.1 / 1,059.5 / 941.8 / 765.2
  • Sound Level (dB(A), high/med/low): 45/40/34
  • External Static Pressure (in. W.C.): 0-0.8
  • Filter Size (in): 21.26 x 10.12
  • Condensate Drain: 1"
  • Unit Dimensions (W x D x H): 47.24 in x 29.53 in x 11.81 in
  • Net / Shipping Weight: 106.26 lb / 120.37 lb

Compatibility

Pair this indoor unit only with a Cooper & Hunter outdoor unit listed as compatible in the manufacturer's match-up and multi-zone combination charts. The outdoor unit, line set, communication cable and installation materials are sold separately. Installation and service require a licensed HVAC technician.

White Paper

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
Cooper & Hunter
Width:
47.20 (in)
Height:
11.80 (in)
Depth:
29.50 (in)
Weight:
120.37 LBS
Prop 65 Warning:
Yes
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Product Category:
Mini Split Indoor Unit
Series:
Slim Duct
Configuration:
Concealed Ducted
Mount Type:
Concealed Ducted
Indoor Air Handler Type(s):
Slim Ducted
Capacity (Tons):
3
Cooling Capacity (BTU):
36,000
Refrigerant Type:
R-454B
Voltage / Phase:
208/230V 1-Phase
Electrical Phase:
1-Phase
Cooling Capacity (BTU/h):
36,000
Refrigerant Piping (Liquid/Gas):
3/8"/3/4"
Airflow (CFM, high to low):
1,236.1 / 1,059.5 / 941.8 / 765.2
Sound Level (dB(A), high/med/low):
45/40/34
External Static Pressure (in. W.C.):
0-0.8
Filter Size (in):
21.26 x 10.12
Condensate Drain:
1"
Unit Dimensions (W x D x H):
47.24 in x 29.53 in x 11.81 in
Net / Shipping Weight:
106.26 lb / 120.37 lb
Unit Weight:
106.26 lb
Ship Weight (lbs):
120.37
Liquid Line Size | OD - Outside Diameter:
3
Suction Line Size | OD - Outside Diameter:
8"
System Type:
Heat Pump
Sound Level Indoor (dB):
34
Airflow (CFM):
1,236.1
Minimum Circuit Ampacity (MCA):
4
Maximum Overcurrent Protection (MOP):
15
Compressor Type:
Inverter
SEER2:
17 SEER2
EER2:
12 EER2
Wi-Fi Control:
Built-In
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
7 Years Compressor & 5 Years Parts | Registration Required within 60 Days of Installation
Frequently asked questions
What size is the ?
The is a 3 ton unit.
How much cooling does the provide?
It is rated for 36,000 BTU of cooling.
What refrigerant does the use?
It uses R-454B refrigerant.
What power supply does the need?
It requires 208/230V 1-Phase power.
What is the SEER2 rating of the ?
The is rated at 17 SEER2 SEER2.
Can the be controlled over Wi-Fi?
Built-In.
What warranty comes with the CH-RS36LCDT-HS?
7 Years Compressor & 5 Years Parts | Registration Required within 60 Days of Installation
Who makes the CH-RS36LCDT-HS?
The CH-RS36LCDT-HS is made by Cooper & Hunter.
