Description
The Goodman 2 Ton 17.2 SEER2 8.1 HSPF2 97% AFUE 60,000 BTU Hybrid Dual Fuel Heat Pump & Gas Furnace Split System Upflow R-32 (GLZT7CA2410 / GRVM970603BN / CAPTA3026B3) is a complete dual fuel heating and cooling system that pairs an electric heat pump with a gas furnace. This AHRI-matched system combines a 2-ton R-32 heat pump, 97% AFUE modulating gas furnace, and cased evaporator coil so the heat pump handles cooling and mild-weather heating, while the furnace takes over when outdoor temperatures drop.
Designed for upflow installation, the system uses the furnace's variable-speed ECM blower motor to move air for both the heat pump and the gas burners. With a dual-fuel thermostat or outdoor temperature control, the system switches to gas heat below a set balance point, which keeps homes comfortable in cold snaps and lets you choose the more economical fuel for your local utility rates.
Key Features
-
2 Ton Cooling Capacity – AHRI-rated 23,800 BTU/h of cooling
-
17.2 SEER2 / 12.5 EER2 – Certified matched-system cooling efficiency
-
8.1 HSPF2 Heat Pump Heating – 23,600 BTU/h at 47°F and 14,000 BTU/h at 17°F
-
60,000 BTU Gas Furnace – Modulating heating with 97% AFUE efficiency
-
Dual Fuel Operation – Heat pump for efficient mild-weather heat, gas furnace for cold-weather backup
-
Upflow R-32 System – Uses lower-GWP R-32 refrigerant
System Components Included
-
Goodman GLZT7CA2410 2 Ton R-32 Heat Pump
-
Goodman GRVM970603BN 60,000 BTU 97% AFUE Modulating Gas Furnace
-
Goodman CAPTA3026B3 Cased Upflow/Downflow R-32 Evaporator Coil
Compatibility & Installation Notes
The GLZT7CA2410 / GRVM970603BN / CAPTA3026B3 system is AHRI certified under reference number 216617578 and is designed for residential upflow applications. Compatibility with the property's ductwork, electrical service, gas supply, refrigerant lines, condensate drainage, and furnace venting must be confirmed before installation. The communicating GLZT7CA2410 heat pump and GRVM970603BN furnace connect over the two communication wires, and the furnace control manages dual fuel switchover on its own, so a standard single-stage 24 VAC thermostat is all you need. No separate dual fuel kit is required.
Specifications
-
System Type: Hybrid Dual Fuel Heat Pump & Gas Furnace Split System
-
AHRI Reference Number: 216617578
-
Cooling Capacity: 23,800 BTU/h
-
Heat Pump Heating Capacity: 23,600 BTU/h at 47°F / 14,000 BTU/h at 17°F
-
Cooling Efficiency: 17.2 SEER2 / 12.5 EER2
-
Heating Efficiency: 8.1 HSPF2
-
Furnace Input / Output: 60,000 / 58,200 BTU/h
-
Furnace Efficiency: 97% AFUE
-
Refrigerant / Orientation: R-32 / Upflow
Installation Notes
-
Verify compatibility with the existing upflow ductwork
-
Confirm electrical service and natural gas connection requirements
-
Check the required refrigerant line sizes before installation
-
Ensure PVC (Category IV) venting for the high-efficiency condensing furnace
-
Connect the 1 and 2 communication wires between the furnace and heat pump and set up the thermostat for single-stage AC and single-stage gas heat
-
Installation should be completed by a qualified HVAC professional
Frequently Asked Questions
What is included in this Goodman HVAC system?
The package includes the GLZT7CA2410 heat pump, GRVM970603BN gas furnace, and CAPTA3026B3 cased evaporator coil.
How does a dual fuel system work?
The heat pump cools in summer and heats in mild weather. When the outdoor temperature falls below the balance point set on the thermostat, the gas furnace takes over heating, so the system always runs on the more effective heat source.
What is the heating rating of the heat pump?
This matched system is rated at 8.1 HSPF2, with 23,600 BTU/h of heat pump heating at 47°F.
What is the cooling capacity of this system?
The system provides 2 tons with an AHRI-rated 23,800 BTU/h of cooling.
Is the furnace single-stage or two-stage?
The Goodman GRVM970603BN is a modulating gas furnace.
What does 97% AFUE mean?
It means approximately 97% of the furnace's fuel is converted into usable heating energy.
Does this system use R-32 refrigerant?
Yes. The heat pump and evaporator coil are designed for R-32 refrigerant.
