Description
Product Summary
The Kramer KL6E105DDAAL is a Next-Gen All-Temp Low Profile unit cooler with 10,500 BTU/h of capacity at -20°F SST, 10°F TD, R-404A. It uses electric defrost and runs on 208/230V 1-phase power.
The unit has 2 fans, 1,550 CFM of airflow, EC 2-Speed fan motors, and is approved for R-404A.
This configuration ships with a factory-mounted R-404A TXV, liquid line solenoid valve and mechanical thermostat, which reduces field piping and wiring time.
Key Features
- Low Profile Design: slim cabinet maximizes usable box height in walk-ins
- Rated Capacity: 10,500 BTU/h at -20°F SST, 10°F TD, R-404A
- Dual-Speed EC Fan Motors: lower energy use and reduced fan speed during off-cycle
- Electric Defrost: factory electric heaters for reliable defrost in low-temperature boxes
- Refrigerant: approved for R-404A
- Factory Pre-Assembly: factory-mounted R-404A TXV, liquid line solenoid valve and mechanical thermostat
- Enhanced Coil: 3/8 in enhanced copper tubes with corrugated aluminum fins
- Balanced 12 in Fans: aluminum fan blades for quiet, even airflow
Specifications
| Brand | Kramer |
|---|---|
| Model | KL6E105DDAAL |
| Series | Next-Gen All-Temp Low Profile |
| Product Type | Low Profile Unit Cooler |
| Profile | Low Profile |
| Refrigeration Capacity | 10,500 BTU/h (-20°F SST, 10°F TD, R-404A) |
| Defrost Type | Electric Defrost |
| Temperature Application | Low Temp |
| Number of Fans | 2 |
| Airflow | 1,550 CFM |
| Fins Per Inch | 6 |
| Fan Motor | EC 2-Speed |
| Fan Motor Amps (208/230V EC) | 1.0 A |
| Defrost Heater | 2,250 W (9.8 A at 208/230V) |
| Liquid / Suction Connection | 3/8 in / 7/8 in |
| Refrigerants | R-404A |
| Factory Package | factory-mounted R-404A TXV, liquid line solenoid valve and mechanical thermostat |
| Voltage / Phase | 208/230V / 1-Phase / 60 Hz |
| Shipping Weight | 62 lb |
| Warranty | 1 Year Parts from Installation or 18 Months from Shipment, Whichever Comes First (Manufacturer Warranty) |
Ideal Applications
- Walk-in freezers
- Restaurants and commercial kitchens
- Convenience stores and grocery freezers
- Ice cream and frozen food storage
- Schools, hospitals and institutional foodservice
Frequently Asked Questions
What is the capacity of the KL6E105DDAAL?
It is rated at 10,500 BTU/h at -20°F SST, 10°F TD, R-404A.
What voltage does the KL6E105DDAAL use?
It runs on 208/230V 1-phase 60 Hz power. Electric defrost heaters are powered from the same supply.
Which refrigerants is it approved for?
It is approved for R-404A.
Is it for a cooler or a freezer?
This electric-defrost unit is designed for low-temperature applications such as walk-in freezers, and can also be used in coolers.
What condensing unit matches this evaporator?
Pick a condensing unit rated for the same refrigerant and temperature, with capacity matched at your design suction temperature. HVAC365 can recommend a matching Kramer condensing unit.
