Description
Product Summary
The Kramer KE6A128ADA is a Center Mount (Low Height) unit cooler with 12,800 BTU/h of capacity at 25°F SST, 10°F TD, R-404A, 115V. It uses air defrost and runs on 115V 1-phase power.
The unit has 3 fans, 1,716 CFM of airflow, EC 2-Speed fan motors, and is approved for R-404A, R-448A and R-449A.
It is intended for walk-in coolers and medium-temperature boxes, and is a good fit for contractors replacing or specifying matched walk-in systems.
Key Features
- Center Mount Design: ceiling center-mount design with dual-direction air throw
- Rated Capacity: 12,800 BTU/h at 25°F SST, 10°F TD, R-404A, 115V
- Dual-Speed EC Fan Motors: lower energy use and reduced fan speed during off-cycle
- Air Defrost: off-cycle air defrost for medium-temperature boxes
- Multiple Refrigerants: approved for R-404A, R-448A and R-449A
Specifications
| Brand | Kramer |
|---|---|
| Model | KE6A128ADA |
| Series | Center Mount (Low Height) |
| Product Type | Center Mount Unit Cooler |
| Profile | Center Mount |
| Refrigeration Capacity | 12,800 BTU/h (25°F SST, 10°F TD, R-404A, 115V) |
| Defrost Type | Air Defrost |
| Temperature Application | Medium Temp |
| Number of Fans | 3 |
| Airflow | 1,716 CFM |
| Fins Per Inch | 6 |
| Fan Motor | EC 2-Speed |
| Fan Motor Amps | 2.4 A (115V) |
| Liquid / Suction Connection | 3/8 in / 7/8 in |
| Refrigerants | R-404A, R-448A, R-449A |
| Voltage / Phase | 115V / 1-Phase / 60 Hz |
| Warranty | 1 Year Parts from Installation or 18 Months from Shipment, Whichever Comes First (Manufacturer Warranty) |
Ideal Applications
- Walk-in coolers
- Restaurants and commercial kitchens
- Convenience stores and grocery coolers
- Floral, beverage and produce storage
- Schools, hospitals and institutional foodservice
Frequently Asked Questions
What is the capacity of the KE6A128ADA?
It is rated at 12,800 BTU/h at 25°F SST, 10°F TD, R-404A, 115V.
What voltage does the KE6A128ADA use?
It runs on 115V 1-phase 60 Hz power.
Which refrigerants is it approved for?
It is approved for R-404A, R-448A and R-449A.
Is it for a cooler or a freezer?
This air-defrost unit is intended for medium-temperature applications such as walk-in coolers held at about 35°F and above.
What condensing unit matches this evaporator?
Pick a condensing unit rated for the same refrigerant and temperature, with capacity matched at your design suction temperature. HVAC365 can recommend a matching Kramer condensing unit.
