Rheem 10 Ton 14.8 IEER Commercial Air Conditioner Condenser, Two Stage, Commercial Classic, 208/230V 3-Phase, R454B | RACY2120CAZ

Rheem 10 Ton 14.8 IEER Commercial Air Conditioner Condenser, Two Stage, Commercial Classic, 208/230V 3-Phase, R454B | RACY2120CAZ
Product details

Description

Rheem 10 Ton Commercial Air Conditioner Condenser (RACY2120CAZ)

The Rheem RACY2120CAZ is a Commercial Classic Series split-system condensing unit for light commercial buildings with 208/230 volt 3-phase service. It is designed to pair with the Rheem RHCYA2120CAS belt-drive VFD air handler; the matched system is AHRI certified (AHRI 214437933).

Cooling performance

  • Nominal capacity: 10 ton (114,000 BTU/h AHRI net cooling with matched air handler)
  • Efficiency: 11.2 EER, 14.8 IEER (AHRI 340/360)
  • Compressor: 1 scroll, 2-stage (RLA 26.5 A, LRA 255 A)
  • Refrigerant: R-454B (A2L)
  • Metering: Matched air handler has non-bleed TXV
  • Sound rating: 88 dB (AHRI 270)

Electrical and piping

  • Power supply: 208/230V 3-Phase, 60 Hz
  • Minimum circuit ampacity: 44 A
  • Overcurrent protection: 60/70 A (min/max)
  • Condenser fans: 2 ECM at 1/2 HP, 5.2 FLA each
  • Recommended line sizes: 5/8" liquid, 1-3/8" or 1-5/8" suction
  • A2L line set: A2L line set size 5/8" (p.17)

Dimensions

  • Operating dimensions: 44.00 H x 74.25 L x 40.00 W in
  • Operating weight: 565 lb
  • Shipping weight: 585 lb

White Paper

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
Rheem
Width:
40.00 (in)
Height:
44.00 (in)
Depth:
74.25 (in)
Weight:
585.00 LBS
Product Category:
Air Conditioner Condenser
Refrigerant Type:
R-454B
Capacity (Tons):
10
Electrical Phase:
3-Phase
Prop 65 Warning:
Yes
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Cooling Capacity (BTU):
114,000
Voltage / Phase:
208/230V 3-Phase
Product Height:
44.0 in
Product Width:
40.0 in
Product Depth:
74.25 in
AHRI Certified:
Yes
EER:
11 EER
IEER:
14 IEER
Compressor Type:
Scroll
Compressor Stages:
Two Stage
Minimum Circuit Ampacity (MCA):
44 A
Maximum Overcurrent Protection (MOP):
70 A
Sound Level (dB):
88
Unit Weight:
565 lb
Shipping Weight:
585 lb
Matched Air Handler:
RHCYA2120CAS
AHRI Reference Number:
214437933
Product Line:
RACY
Warranty Information:
5 Years Compressor & 1 Year Parts
Electrical Frequency:
60 Hz
DOE Regional Compliance:
Nationwide
Breaker Size (Amps):
70
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
5 Years Compressor & 1 Year Parts | Registration Required within 60 Days of Purchase
Videos2 videos
Rheem Family of Brands: Heating, Cooling & Water Heating
Frequently asked questions
What refrigerant does the use?
It uses R-454B refrigerant.
What size is the ?
The is a 10 ton unit.
How much cooling does the provide?
It is rated for 114,000 BTU of cooling.
What power supply does the need?
It requires 208/230V 3-Phase power.
Is the AHRI certified?
Yes. The AHRI reference number is 214437933.
What warranty comes with the RACY2120CAZ?
5 Years Compressor & 1 Year Parts | Registration Required within 60 Days of Purchase
Who makes the RACY2120CAZ?
The RACY2120CAZ is made by Rheem.
