Rheem 6.5 Ton 11.2 EER Commercial Air Conditioner Condenser, 2-Stage, 208/230V 3-Phase, R454B | RACY2078CAZ

Rheem

5 Star RatingLeave a review
No reviews yet Write a Review
SKU:
RACY2078CAZ
Your Price $0.00
Detecting ZIP...
Est. Net Incentive Amount: $0.00
We could not detect your ZIP automatically. Enter your ZIP to check incentives.
Available Incentives
$0.00
Selected Incentives
0
Unpriced Programs
0
Estimates assume eligibility; programs and amounts can change.
Learn more about incentives
Rheem 6.5 Ton 11.2 EER Commercial Air Conditioner Condenser, 2-Stage, 208/230V 3-Phase, R454B | RACY2078CAZ
UPC:
662021686313
Condition:
New
Width:
35.75 (in)
Height:
51.00 (in)
Depth:
35.75 (in)

Questions about Rheem 6.5 Ton 11.2 EER Commercial Air Conditioner Condenser, 2-Stage, 208/230V 3-Phase, R454B | RACY2078CAZ?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business
View Certification

Fast Shipping

Customer Support

Warranty Coverage

Financing Available

$12,883.20
  • Qualifies for FREE Shipping
2 in stock • Ships in 1-2 Business Days
Overview

Rheem 6.5 Ton 11.2 EER Commercial Air Conditioner Condenser, 2-Stage, 208/230V 3-Phase, R454B | RACY2078CAZ

Rheem 6.5 Ton 11.2 EER Commercial Air Conditioner Condenser, 2-Stage, 208/230V 3-Phase, R454B | RACY2078CAZ
Product details

Description

Rheem 6.5 Ton Commercial Air Conditioner Condenser (RACY2078CAZ)

The Rheem RACY2078CAZ is a Commercial Classic Series RACY split-system condensing unit for light commercial buildings with 208/230 volt 3-phase service. It pairs with the Rheem RHCYA2090CAS belt-drive commercial air handler, which is the AHRI-rated indoor match for this size. It is the outdoor half of a split system: the condenser sits on a pad or roof, and refrigerant lines run to the air handler inside.

Performance

  • Nominal capacity: 6.5 ton (72,200 BTU/h net cooling per the Rheem spec sheet)
  • Efficiency: 11.2 EER, 14.8 IEER when matched with the RHCYA2090CAS air handler
  • Compressor: 1 scroll, 2-stage
  • Staging: Two stages of cooling for part-load operation
  • Refrigerant: R-454B (A2L)
  • Sound rating: 86 dB (AHRI 270)

Electrical

  • Power supply: 208/230V 3-Phase, 60 Hz
  • Minimum circuit ampacity: 39 A
  • Overcurrent protection: 45 A minimum / 60 A maximum
  • Compressor: RLA 26.3 A, LRA 178.5 A

Cabinet

  • Dimensions: 51 in H x 35.75 in L x 35.75 in W
  • Operating weight: 383 lb
  • Shipping weight: 403 lb

Line set sizing for R-454B depends on run length and lift; follow the Rheem RACY installation instructions. Metering is handled by the TXV in the matched air handler.

White Paper

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
Rheem
Width:
35.75 (in)
Height:
51.00 (in)
Depth:
35.75 (in)
Weight:
403.00 LBS
Refrigerant Type:
R-454B
Product Height:
51 in
Product Width:
35.75 in
Product Depth:
35.75 in
Capacity (Tons):
6.5
Cooling Capacity (BTU):
72,200
EER:
11 EER
IEER:
14 IEER
Electrical Phase:
3-Phase
Voltage / Phase:
208/230V 3-Phase
Product Category:
Air Conditioner Condenser
Product Line:
RACY
Compressor Type:
Scroll
Compressor Stages:
Two Stage
Minimum Circuit Ampacity (MCA):
39 A
Maximum Overcurrent Protection (MOP):
60 A
Sound Level (dB):
86
Unit Weight:
383 lb
Shipping Weight:
403 lb
Matched Air Handler:
RHCYA2090CAS
Metering Device:
TXV (in matched air handler)
Prop 65 Warning:
Yes
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Warranty Information:
5 Years Compressor & 1 Year Parts
Electrical Frequency:
60 Hz
DOE Regional Compliance:
Nationwide
Breaker Size (Amps):
60
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
5 Years Compressor & 1 Year Parts | Registration Required within 60 Days of Purchase
Videos1 videos
Rheem Commercial: Extremely Tested. Extremely Tough.
Frequently asked questions
What refrigerant does the use?
It uses R-454B refrigerant.
What size is the ?
The is a 6.5 ton unit.
How much cooling does the provide?
It is rated for 72,200 BTU of cooling.
What power supply does the need?
It requires 208/230V 3-Phase power.
What warranty comes with the RACY2078CAZ?
5 Years Compressor & 1 Year Parts | Registration Required within 60 Days of Purchase
Who makes the RACY2078CAZ?
The RACY2078CAZ is made by Rheem.
