Description
Overview
This LG Multi F MAX heat pump system pairs the KUMXB541A outdoor unit with 5 LG Multi F standard wall-mounted indoor units for five-zone heating and cooling. Every indoor unit in this system is the same style, so each room gets matching appearance, airflow and controls. The system runs on 208/230V, 1-phase, 60 Hz power and uses R-32 refrigerant.
What Is Included
- 1 x KUMXB541A multi-zone outdoor unit (up to 8 indoor units through branch distribution units, LG R1 twin rotary inverter compressor)
- 1 x KNUAB091A (9,000 BTU LG Multi F standard wall-mounted indoor unit)
- 2 x KNUAB121A (12,000 BTU LG Multi F standard wall-mounted indoor unit)
- 2 x KNUAB181A (18,000 BTU LG Multi F standard wall-mounted indoor unit)
- 1 x PMBD3641ZR 4-port branch distribution unit
- 1 x PMBD3630ZR 3-port branch distribution unit
- 1 x ARBLN03321 Y-branch kit (connects the two branch distribution units)
Performance
LG rates Multi F MAX systems by total connected indoor capacity. At 69,000 BTU/h connected (non-ducted), this system is rated at 20.6 SEER2, 12.6 EER2 and 9.5 HSPF2, with a rated cooling capacity of 50,500 BTU/h and a rated heating capacity of 58,000 BTU/h. Heating operation is rated down to -4 F outdoor temperature (wet bulb) and cooling operation from 14 F to 118 F.
Comfort and Noise
Each zone has its own indoor unit and set point, so occupied rooms can be conditioned independently while unused rooms stay idle. The inverter compressor adjusts its speed to match the load, which holds temperatures steadily and reduces on/off cycling.
Smart Features
These indoor units have built-in Wi-Fi for control through the LG ThinQ app. Each indoor unit includes a wireless remote controller.
Use Case Fit
Wall-mounted indoor units suit bedrooms, offices, living rooms and additions where a high wall location is available. Confirm room loads, line set lengths and electrical requirements before ordering. Professional installation is recommended.
Value and Reliability
Bundling the outdoor unit with matched indoor units and branch distribution units in one product simplifies ordering. Warranty: 7 Years Compressor & 5 Years Parts | Registration Required within 60 Days of Purchase.
Key Features
- Five-zone system: 9K + 12K + 12K + 18K + 18K
- 20.6 SEER2 / 9.5 HSPF2
- R-32 refrigerant
- Heating down to -4 F
- Single indoor style throughout: LG Multi F standard wall-mounted
