Mitsubishi R410A Blowout Sale – limited quantities. This tri-zone system is sold as a complete matched package only. The outdoor unit and indoor units in this bundle are not sold separately.
Overview
This Mitsubishi Electric tri-zone ductless heat pump system pairs the MXZ-3C24NAHZ4 M-Series H2i Hyper-Heating multi-zone outdoor unit with 2 x MSZ-GS06NA (6,000 BTU/h), MSZ-FW12NA (12,000 BTU/h) wall-mounted indoor units, for a total connected capacity of 24,000 BTU/h across 3 independently controlled zones. The outdoor unit runs on 208/230V, 1-phase, 60 Hz power and uses a variable-speed INVERTER-driven twin rotary compressor with R410A refrigerant.
Performance
Rated non-ducted performance for the MXZ-3C24NAHZ4 is 22,000 BTU/h cooling and 25,000 BTU/h heating at 47°F, with 14,000 BTU/h at 17°F and up to 25,000 BTU/h maximum heating at 5°F. Efficiency is rated at 19.0 SEER2, 13.5 EER2 and 10.0 HSPF2. As an H2i Hyper-Heating model, it keeps heating down to -13°F outdoor (wet bulb), which makes it a strong fit for cold climates. Cooling operates from 14°F to 115°F outdoor.
Smart Features
- MSZ-FW12NA: built-in Wi-Fi with app control, 3D i-see Sensor that maps room occupancy and temperature, and dual vanes for independent airflow control.
- MSZ-GS indoor units: compatible with the kumo cloud app through an optional Wi-Fi adapter, plus wired or wireless controller options.
- Each zone has its own handheld remote and setpoint, so unused rooms can be turned down or off.
- Automatic restart after a power outage.
Comfort and Noise
Indoor units run as quiet as 19 dB(A) on the lowest fan speed, and the outdoor unit is rated at 54 dB(A) cooling and 58 dB(A) heating. Variable-speed operation matches output to the load, which reduces temperature swings and drafts compared with single-speed equipment.
Use Case Fit
This 6K + 6K + 12K combination suits three rooms, such as bedrooms plus a home office or a living area, as well as additions, condos and older homes without ductwork. Smaller 6K heads fit bedrooms and offices, while the 12K head handles a larger living space.
Value and Reliability
Mitsubishi Electric multi-zone systems are known for long service life and low operating cost. The outdoor coil uses Blue Fin anti-corrosion treatment, and the indoor units use Dual Barrier Coating to keep the fan and coil cleaner. Warranty is 7 years on the compressor and 5 years on parts with registration within 90 days of purchase. This blowout price is well below buying the same components individually.
Summary Wrap-Up
A complete, matched Mitsubishi M-Series H2i Hyper-Heating tri-zone package with 6K + 6K + 12K wall-mounted indoor units, sold as a bundle only at blowout pricing while stock lasts. Installation by a licensed HVAC professional is required; line sets, communication wire, disconnects and pads are not included.
Key Features
- Matched system: MXZ-3C24NAHZ4 outdoor unit with 2 x MSZ-GS06NA (6,000 BTU/h), MSZ-FW12NA (12,000 BTU/h).
- 3 zones: each room gets its own indoor unit and remote.
- Efficiency: 19.0 SEER2 / 10.0 HSPF2 (non-ducted).
- Hyper-Heating H2i: heating down to -13°F outdoor.
- INVERTER-driven twin rotary compressor for variable-speed comfort.
- R410A refrigerant, factory pre-charged for up to 98 ft of piping.
Outdoor Unit Specifications – MXZ-3C24NAHZ4
| Nominal Capacity | 24,000 BTU/h class |
|---|---|
| Rated Cooling (non-ducted) | 22,000 BTU/h |
| Rated Heating at 47°F | 25,000 BTU/h |
| Rated Heating at 17°F | 14,000 BTU/h |
| Heating at 5°F | 25,000 (max) BTU/h |
| SEER2 / EER2 / HSPF2 | 19.0 / 13.5 / 10.0 |
| Indoor Units | 2 to 3 (connected capacity 12,000–27,000 BTU/h) |
| Compressor | DC INVERTER-driven twin rotary |
| Refrigerant | R410A |
| Electrical | 208/230V, 1-phase, 60 Hz |
| MCA / MOCP | 31.5 A / 40 A |
| Outdoor Sound (cool / heat) | 54 / 58 dB(A) |
| Liquid Line | 1/4 in (ports A, B, C) |
| Gas Line | 1/2 in (port A); 3/8 in (ports B, C) |
| Piping Length | 230 ft total; 82 ft farthest indoor unit |
| Operating Range | Cooling 14–115°F DB; heating -13–65°F WB |
| Dimensions (W x D x H) | 37-13/32 in x 13 in x 41-17/64 in |
| Unit / Shipping Weight | 189 lb / 218 lb |
Indoor Unit Specifications – MSZ-GS06NA (qty 2)
| Type | GS-series wall-mounted indoor unit |
|---|---|
| Cooling Capacity | 6,000 BTU/h |
| Heating Capacity | 7,200 BTU/h |
| Airflow | 134-390 CFM |
| Sound Level | 19-45 dB(A) |
| Refrigerant | R410A |
| Liquid / Gas Line | 1/4 in / 3/8 in flare |
| Drain | 5/8 in |
| Dimensions (W x D x H) | 31-7/16 in x 9-1/8 in x 11-5/8 in |
| Unit / Shipping Weight | 23 lb / 26 lb |
Indoor Unit Specifications – MSZ-FW12NA
| Type | FW-series wall-mounted indoor unit with built-in Wi-Fi |
|---|---|
| Cooling Capacity | 12,000 BTU/h |
| Heating Capacity | 13,200 BTU/h |
| Airflow | 168-533 CFM |
| Sound Level | 20-44 dB(A) |
| Refrigerant | R410A |
| Liquid / Gas Line | 1/4 in / 3/8 in flare |
| Drain | 5/8 in |
| Dimensions (W x D x H) | 39-9/32 in x 9-3/4 in x 12 in |
| Unit / Shipping Weight | 31.4 lb / 36.4 lb |
What's Included
- 1 x MXZ-3C24NAHZ4 outdoor unit
- 2 x MSZ-GS06NA wall-mounted indoor unit with remote
- 1 x MSZ-FW12NA wall-mounted indoor unit with remote
Not included: line sets, communication cable, electrical disconnect, condensate pump or line hide, and mounting pad/brackets.
