Description
The MRCOOL Advantage 5th Gen A-36-HP-C-230D-O is the 36,000 BTU (3-ton) outdoor heat pump condenser for a single-zone ductless mini split, rated up to 18 SEER2 and 8.5 HSPF2 on low-GWP R-454B refrigerant. A DC inverter rotary compressor varies its speed to hold temperature quietly and efficiently in both cooling and heating.
Give yourself an advantage literally with our 5th Generation 36k BTU 230V Advantage condenser. This Advantage unit must be installed by an HVAC professional, which will be a relatively fast and inexpensive process, as ductless mini splits typically have an easier installation than most HVAC units. This 36k BTU unit is perfect if you need to cover a space that is up to and around 1,550 sq. ft. space in efficient, reliable comfort.
Covering a large space won’t break the bank, either, because this unit achieves a SEER2 rating of 18 as well as an HSPF2 4 rating of 8.5, meaning you can bring your space to whatever temperature you want without watching your bills skyrocket. A new refrigerant, R454B, gives this system an edge over its previous generation, which used R410A.
This means that the 5th Generation Advantage is a much more environmentally sound and energy efficient option because R454B has a GWP (global warming potential) that is 80 percent lower than the refrigerant used in the previous generation, which makes this system a great choice for you and everyone on the planet.
It’s an incredibly convenient choice, too, because it includes a Wi Fi module, which enables control of your system through your phone and Amazon Alexa or Google Home, giving you the ability to control your space’s temperature with just your voice.
Choose a 5th Generation 36k BTU Advantage for the best home comfort that you’ve always deserved.
Key Features
- DC inverter compressor: Variable-speed rotary compressor ramps to the load for steady comfort and low energy use.
- R-454B refrigerant: Low-GWP A2L refrigerant.
- Efficiency: Up to 18 SEER2 / 9 EER2 / 8.5 HSPF2.
- Quiet outdoor operation: 60.5 dBA rated sound level.
- Long line runs: Up to 213.2 ft maximum line set length.
Product Specifications
| Unit Dimensions (W x D x H) | 37.24" x 16.14" x 31.89" |
|---|---|
| Unit Weight | 150.35 lb |
| Max Coverage Area | Up to 1,550 sq ft |
| Brand | MRCOOL |
| Model | A-36-HP-C-230D-O |
| Series | Advantage 5th Gen |
| SEER2 | 18 |
| EER2 | 9 |
| HSPF2-4 | 8.5 |
| HSPF2-5 | 6.8 |
| Tonnage | 3 |
| Cooling Capacity | 36000 BTU |
| Heating Capacity | 36000 BTU |
| Voltage | 208–230V |
| Phase | 1 |
| Cycle | 60Hz |
| Max Fuse Breaker | 35A |
| Min Circuit Ampacity | 33A |
| Zone Capacity | 1 |
| Refrigerant Type | R-454B |
| Refrigerant Volume | 112.88 oz |
| Decibel Rating | 60.5 dBA |
| Inverter | DC |
| Max Line Set Length | 213.2 ft |
| Liquid Line Size | 3/8 in |
| Suction Line Size | 5/8 in |
| Compressor Motor Type | Rotary |
| Overload Protection | Yes |
| UL Listed | Yes |
| Csa Listed | Yes |
| ETL Listed | Yes |
| Energy Star Certified | No |
| AHRI Certified | Yes |
| Net Dimensions | 16.14 in D × 31.89 in H × 37.24 in W |
| Net Weight | 150.35 lbs |
Compatibility & Installation
Matched with:
- Line set: Flare connections — 3/8 in liquid × 5/8 in suction; maximum line length 213.2 ft. Line set not included.
- Electrical: 208/230V single-phase, 60 Hz.
- Professional installation: Requires installation by a licensed HVAC technician (evacuation and charge verification with gauges). R-454B is an A2L refrigerant — follow current codes.
