Rheem 10 Ton Commercial Heat Pump Condenser (RPCY2120DAZ)

The Rheem RPCY2120DAZ is a Commercial Classic Series split heat pump outdoor unit for light commercial buildings with 460 volt 3-phase service. It is designed to pair with the Rheem RHCYP2120DAS belt-drive VFD air handler (heat pump version); the matched system is AHRI certified (AHRI 214437993).

Cooling performance

  • Nominal capacity: 10 ton (114,000 BTU/h AHRI net cooling with matched air handler)
  • Efficiency: 11.0 EER, 14.1 IEER (AHRI 340/360)
  • Compressor: 1 scroll, 2-stage (RLA 14 A, LRA 123 A)
  • Refrigerant: R-454B (A2L)
  • Metering: Matched RHCYP air handler has TXV
  • Sound rating: 88 dB (AHRI 270)

Heating performance (AHRI, with matched RHCYP)

  • 47°F: 108,000 BTU/h, COP 3.4
  • 17°F: 57,000 BTU/h, COP 2.25
  • Low ambient control: RXAD-A08 accessory

Electrical and piping

  • Power supply: 460V 3-Phase, 60 Hz
  • Minimum circuit ampacity: 24 A
  • Overcurrent protection: 30/35 A (min/max)
  • Condenser fans: 2 ECM at 3/4 HP (electrical table p.10 lists No. 1, 3 FLA each)
  • A2L line set: 10-ton II knockouts: liquid 5/8" hole, suction 1-5/8" hole (p.17)

Dimensions

  • Operating dimensions: 44 H x 74-17/63 L x 40 W in
  • Operating weight: 642 lb
  • Shipping weight: 662 lb

White Paper

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
Rheem
Width:
40.00 (in)
Height:
44.00 (in)
Depth:
74.27 (in)
Weight:
662.00 LBS
Refrigerant Type:
R-454B
Product Height:
44.0 in
Product Width:
40.0 in
Product Depth:
74.27 in
AHRI Certified:
Yes
Capacity (Tons):
10
Cooling Capacity (BTU):
114,000
EER:
11 EER
IEER:
14 IEER
Heating Capacity at 47F (BTU):
108,000
COP at 47F:
3.4
Heating Capacity at 17F (BTU):
57,000
COP at 17F:
2.25
Electrical Phase:
3-Phase
Voltage / Phase:
460V 3-Phase
Compressor Type:
Scroll
Compressor Stages:
Two Stage
Minimum Circuit Ampacity (MCA):
24 A
Maximum Overcurrent Protection (MOP):
35 A
Sound Level (dB):
88
Unit Weight:
642 lb
Shipping Weight:
662 lb
Matched Air Handler:
RHCYP2120DAS
AHRI Reference Number:
214437993
Prop 65 Warning:
Yes
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Product Category:
Heat Pump Condenser
Product Line:
RPCY
Warranty Information:
5 Years Compressor & 1 Year Parts
DOE Regional Compliance:
Nationwide
Breaker Size (Amps):
35
Electrical Frequency:
60 Hz
