Rheem 3 Ton 14.3 SEER2 Air Conditioner Split System, 460V 3-Phase Condenser, with Multi-Position ECM Constant Torque Air Handler (460V 3-Phase), R454B | RA15AY36AD1NA RH2TY3617STANND

Rheem

5 Star RatingLeave a review
No reviews yet Write a Review
SKU:
RA15AY36AD1NA-RH2TY3617STANND
Your Price $0.00

Detecting ZIP...
Est. Net Incentive Amount: $0.00
We could not detect your ZIP automatically. Enter your ZIP to check incentives.
Available Incentives
$0.00
Selected Incentives
0
Unpriced Programs
0
Estimates assume eligibility; programs and amounts can change.
Condition:
New
Width:
33.80 (in)
Height:
31.00 (in)
Depth:
33.80 (in)

Questions about Rheem 3 Ton 14.3 SEER2 Air Conditioner Split System, 460V 3-Phase Condenser, with Multi-Position ECM Constant Torque Air Handler (460V 3-Phase), R454B | RA15AY36AD1NA RH2TY3617STANND?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business

Fast Shipping

Customer Support

Warranty Coverage

Financing Available

$10,770.82

  • Qualifies for FREE Shipping
0 in stock • Ships in 1-2 Business Days
Overview

Rheem 3 Ton 14.3 SEER2 Air Conditioner Split System, 460V 3-Phase Condenser, with Multi-Position ECM Constant Torque Air Handler (460V 3-Phase), R454B | RA15AY36AD1NA RH2TY3617STANND

Rheem 3 Ton 14.3 SEER2 Air Conditioner Split System, 460V 3-Phase Condenser, with Multi-Position ECM Constant Torque Air Handler (208/230V 1-Phase), R454B | RA15AY36AD1NA RH2TY3617STANNJ
Product details

Description

Rheem 3 Ton Air Conditioner Split System (RA15AY36AD1NA + RH2TY3617STANND)

This AHRI-certified Rheem split system pairs the RA15AY36AD1NA condenser (460V 3-Phase) with the RH2TY3617STANND multi-position air handler. Both the outdoor unit and the air handler run on 460V three-phase power, so the whole system is served from the building's 460V service with no separate single-phase circuit needed for the indoor unit.

The system is cooling only. Electric heat can be added inside the air handler with a Rheem RXBH heat kit offered on this listing.

System performance

  • AHRI reference number: 216011272
  • Rated cooling capacity: 33,200 BTU/h
  • Efficiency: 14.3 SEER2, 9.0 EER2 (AHRI 210/240)
  • Refrigerant: R-454B (A2L)

Condenser: RA15AY36AD1NA

  • Series: RA15AY
  • Compressor: Scroll, single-stage
  • Power supply: 460V 3-Phase, 60 Hz
  • MCA / MOP: 6 A / 15 A
  • Refrigerant connections: 3/8" liquid, 3/4" suction
  • Sound rating: 72 dB
  • Dimensions: 33.75 in W x 33.75 in D x 31.0 in H
  • Weight: 210 lb operating / 217 lb shipping

Air handler: RH2TY3617STANND

  • Type: RH2TY multi-position (upflow, downflow, horizontal), N-coil with TXV
  • Blower: Constant-torque ECM, multi-speed, 460V 3-phase
  • Cabinet: 42-1/2 in H x 17-1/2 in W
  • Filter: 16 x 20 in
  • Refrigerant connections: 3/8" liquid, 3/4" vapor

Electric heat options

Rheem 460V RXBH heater kits approved for the RH2TY3617STANND in the Rheem 480V heater table: RXBH-17A07D-B (7.2 kW), RXBH-17A10D-B (9.6 kW), RXBH-17A15D-B (14.4 kW). Choose one in the "Add an Electric Heat Strip" option; the kit is sold separately and is not included in the system price.

White Paper

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
Rheem
Width:
33.80 (in)
Height:
31.00 (in)
Depth:
33.80 (in)
Weight:
327.00 LBS
AHRI Certified:
Yes
AHRI Reference Number:
216011272
Refrigerant Type:
R-454B
Capacity (Tons):
3
Cooling Capacity (BTU):
33,200
SEER2:
14 SEER2
EER2:
9 EER2
Product Category:
Air Conditioner Split System
Product Line:
RA15AY / RH2TY
Outdoor Unit Model:
RA15AY36AD1NA
Air Handler Model:
RH2TY3617STANND
Voltage / Phase:
460V 3-Phase (condenser), 460V 3-Phase (air handler)
Electrical Phase:
3-Phase
Compatible Electric Heat Kits:
RXBH-17A07D-B (7.2 kW), RXBH-17A10D-B (9.6 kW), RXBH-17A15D-B (14.4 kW)
Electric Heat Options (kW):
7, 10, 14
Outdoor Unit RA15AY36AD1NA - UPC:
662021717642
Prop 65 Warning:
Yes
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Condenser RA15AY36AD1NA - Nominal Capacity (Tons):
3
Condenser RA15AY36AD1NA - Refrigerant:
R-454B
Condenser RA15AY36AD1NA - Voltage/Phase/Hz:
460V 3-Phase / 60 Hz
Condenser RA15AY36AD1NA - Minimum Circuit Ampacity (MCA):
6 A
Condenser RA15AY36AD1NA - Maximum Overcurrent Protection (MOP):
15 A
Condenser RA15AY36AD1NA - Compressor Type:
Scroll, single-stage
Condenser RA15AY36AD1NA - Sound Level (dB):
72
Condenser RA15AY36AD1NA - Unit Dimensions:
33.75 in W x 33.75 in D x 31.0 in H
Condenser RA15AY36AD1NA - Shipping Weight:
217 lb
Air Handler RH2TY3617STANND - Nominal Capacity (Tons):
3
Air Handler RH2TY3617STANND - Blower Motor Type:
ECM Constant Torque
Air Handler RH2TY3617STANND - Configuration:
Multi-Position
Air Handler RH2TY3617STANND - Coil Type:
N-coil
Air Handler RH2TY3617STANND - Metering Device:
TXV
Air Handler RH2TY3617STANND - Voltage/Phase/Hz:
460V 3-Phase / 60 Hz
Air Handler RH2TY3617STANND - Liquid Line Size:
3/8 in
Air Handler RH2TY3617STANND - Suction Line Size:
3/4 in
Air Handler RH2TY3617STANND - Cabinet Size:
42-1/2 in H x 17-1/2 in W
Air Handler RH2TY3617STANND - Filter Size:
16 x 20 in
Electrical Frequency:
60 Hz
DOE Regional Compliance:
Nationwide
Air Handler RH2TY3617STANND - UPC:
662021697692
Warranty Information:
10 Years Parts | Registration Required within 60 Days
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase
Videos2 videos
Introducing the All-New Rheem® Endeavor® Line
Frequently asked questions
Is the AHRI certified?
Yes. The AHRI reference number is 216011272.
What refrigerant does the use?
It uses R-454B refrigerant.
What size is the ?
The is a 3 ton unit.
How much cooling does the provide?
It is rated for 33,200 BTU of cooling.
What is the SEER2 rating of the ?
The is rated at 14 SEER2 SEER2.
What power supply does the need?
It requires 460V 3-Phase (condenser), 460V 3-Phase (air handler) power.
What warranty comes with the RA15AY36AD1NA-RH2TY3617STANND?
10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase
Who makes the RA15AY36AD1NA-RH2TY3617STANND?
The RA15AY36AD1NA-RH2TY3617STANND is made by Rheem.
