Description
Overview
The Tosot Cosmo 36,000 BTU ceiling cassette mini split is a complete single-zone heat pump system: indoor unit, inverter outdoor unit, remote and installation package. It is rated at 21 SEER2 and 8.5 HSPF2, runs on 208/230V single-phase power and uses R32 refrigerant.
Ceiling cassettes sit flush in a drop ceiling and spread air in several directions, which suits open offices, retail space, restaurants and large living areas. This system is sized for up to about 1,800 sq. ft.
Key Features
- Commercial-grade airflow: High-CFM indoor sections for large rooms, open plans, shops and offices.
- DC inverter compressor: Smooth, efficient capacity control with R32 refrigerant.
- Wi-Fi control: TOSOT+ app control and scheduling.
- Built-in safety: Refrigerant leak detection and condensate overflow protection where equipped.
- Wide operating range: Reliable cooling and heating across extreme outdoor temperatures.
- 8-way airflow with 7-speed fan control for customized comfort
- Powerful cooling and heating performance
- Automatic drainage system with integrated float switch
- Auxiliary electric heater for faster warm-up
- Easy operation via included remote control
Performance & Efficiency
Rated capacity is 33,600 BTU/h cooling and 34,000 BTU/h heating, with an EER/COP of 3.2 / 3.65 W/W. The inverter compressor ramps up quickly to reach the setpoint, then slows down to hold it, which avoids the on/off cycling of single-speed equipment and cuts power use. The outdoor unit is rated to operate from -13 – 122°F.
Comfort & Control
Every indoor unit includes a wireless remote, and the TOSOT+ app adds Wi-Fi control, scheduling and voice control through Alexa or Google Home. Sleep, quiet and turbo modes, auto restart after a power outage and a dehumidification (dry) mode are built in.
Specifications
System Performance
| Model | GWH36ATEXH-D6DNA1G/O (outdoor) |
|---|---|
| Cooling Capacity | 33,600 BTU/h |
| Heating Capacity | 34,000 BTU/h |
| SEER2 / HSPF2 | 21 / 8.5 |
| EER / COP | 3.2 / 3.65 W/W |
| Coverage Area | Up to 1,800 sq. ft. |
| Outdoor Operating Range | -13 to 122°F |
| Power Supply | 208/230V, 1Ph, 60Hz |
| Rated Current | 20 A |
| Rated Input Power | 4,000 W |
| Minimum Circuit Ampacity (MCA) | 26 A |
| Max Overcurrent Protection (MOP) | 30 A |
Indoor Unit (8-Way Ceiling Cassette)
| Airflow | 1,071 CFM |
|---|---|
| Sound Level | 39–52 dB(A) |
| Dimensions (W x H x D) | Body 33.1 x 33.1 x 9.5; panel 37.4 x 37.4 x 2.05 in |
| Net / Shipping Weight | 50.7 lb / 63.9 lb |
Outdoor Unit
| Compressor | DC inverter |
|---|---|
| Dimensions (W x H x D) | 39.4 x 29.4 x 16.8 in |
| Net / Shipping Weight | 122.4 lb / 133.4 lb |
Line Set & Piping
| Included Copper Line Set | 16 ft, pre-flared |
|---|---|
| Line Sizes | 1/4" liquid / 5/8" gas (flare) |
| Signal Cable / Power Cord | 19 ft / 19 ft |
| Max Line Length / Height | 131.2 ft / 82 ft |
| Refrigerant | R32 |
What's Included
- Indoor unit
- Outdoor unit
- Wireless remote controller
- 16 ft pre-flared copper line set, signal cable and power cord
Installation
Professional installation by a licensed HVAC technician is recommended to protect performance and warranty coverage. Plan the indoor unit location, line set route, condensate drain and a dedicated electrical circuit before ordering.
Frequently Asked Questions
Is this a heat pump?
Yes. It provides both cooling and heating.
How large a space can it handle?
Up to about 1,800 sq. ft. under typical conditions. Rooms with high ceilings, lots of glass or poor insulation may need more capacity.
What warranty does it carry?
Tosot covers the system for 5 years.
Can I control it from my phone?
Yes. The TOSOT+ app provides Wi-Fi control, schedules and voice control with Alexa and Google Home.
