Find your comfort-ready size with confidence
Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.
Quick sizing snapshot
Enter your home size and a few basics to see a quick HVAC365 sizing snapshot you can review with a Professional.
Enter at least 100 sq ft.
Use conditioned square footage only; skip garages and unfinished basements.
We’ll auto-detect for U.S. visitors.
Select your home type.
Shared walls and insulation levels change the load—pick what matches your structure.
Choose a system type.
Match the system to your ductwork, fuel, or preferred heat source for best comfort.
Your sizing results
Tonnage
—
Cooling capacity
Cooling BTU
—
Estimated load
Heating BTU
—
Estimated load
System type
—
Selected preference
This is a sizing estimate for general guidance only. Always confirm final size, duct design, and fuel type with a Professional before purchasing equipment or pulling permits.
Brand:
Comfortstar
Width:
28.00
(in)
Height:
33.50
(in)
Depth:
28.00
(in)
Weight:
161.00 LBS
Product Width:
28
Suction Line Size:
3/4 in
SEER2:
14 SEER2
Refrigerant Type:
R-454B
Shipping Weight:
170 lb
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Type:
Air Conditioner Condenser
AHRI Certified:
Yes
Air Conditioner Condenser Series:
BAR7
ETL Listed:
Yes
Electrical Frequency:
60 Hz
Energy Star Listed:
No
Designed for:
R454B Refrigerant
Electrical Phase:
1-Phase
DOE Regional Compliance:
Nationwide
Compressor Type:
Rotary
Capacity (Tons):
2.5
Cooling Capacity (BTU):
28,000
Compressor Stages:
Single Stage
Minimum Circuit Ampacity (MCA):
16.4
Product Height:
33 3/16
Operating Mode:
Cooling Only
Product Category:
Air Conditioner Condenser
Product Depth:
28
Unit Weight:
161 lb
Product Line:
BAR7
Maximum Overcurrent Protection (MOP):
28.4
Liquid Line Size:
3/8 in
Prop 65 Warning:
Yes
Voltage / Phase:
208/230V 1-Phase
Please Note:
To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.
