Daikin 21,000 BTU Wall Mounted Dual Zone Ductless Mini Split Heat Pump Wall 9K + 12K MXTH Series with Wi-Fi | 3MXTH24AVJU9-FTXV09AVJU9-FTXV12AVJU9

Daikin

5 Star RatingLeave a review
No reviews yet Write a Review
SKU:
3MXTH24AVJU9-FTXV09AVJU9-FTXV12AVJU9
Your Price $0.00
Detecting ZIP...
Est. Net Incentive Amount: $0.00
We could not detect your ZIP automatically. Enter your ZIP to check incentives.
Available Incentives
$0.00
Selected Incentives
0
Unpriced Programs
0
Estimates assume eligibility; programs and amounts can change.
Learn more about incentives
Complete system: Daikin 21,000 BTU Wall Mounted Dual Zone Ductless Mini Split Heat Pump Wall 9K + 12K MXTH Series with Wi-Fi - complete system with included remote
UPC:
647379452384
Condition:
New
Width:
43.31 (in)
Height:
34.25 (in)
Depth:
18.13 (in)

Questions about Daikin 21,000 BTU Wall Mounted Dual Zone Ductless Mini Split Heat Pump Wall 9K + 12K MXTH Series with Wi-Fi | 3MXTH24AVJU9-FTXV09AVJU9-FTXV12AVJU9?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business
View Certification

Fast Shipping

Customer Support

Warranty Coverage

Financing Available

$6,421.00
  • Qualifies for FREE Shipping
2 in stock • Ships in 2-3 Business Days
Overview

Daikin 21,000 BTU Wall Mounted Dual Zone Ductless Mini Split Heat Pump Wall 9K + 12K MXTH Series with Wi-Fi | 3MXTH24AVJU9-FTXV09AVJU9-FTXV12AVJU9

Complete system: Daikin 21,000 BTU Wall Mounted Dual Zone Ductless Mini Split Heat Pump Wall 9K + 12K MXTH Series with Wi-Fi - complete system with included remote
Product details

Description

Product Summary

This Daikin Aurora MXTH dual-zone system pairs the 3MXTH24AVJU9 24,000 BTU (2 ton) multi-zone outdoor unit with 2 wall-mounted indoor units (9K + 12K). Each room gets its own indoor unit and its own wireless remote, so you can set a different temperature in every zone.

Aurora is Daikin's cold-climate line: the outdoor unit keeps heating down to -13°F and has an anti-corrosion coated coil. This MXTH version adds a factory-installed drain pan heater that keeps defrost water from freezing in the base pan.

With non-ducted indoor units like these, the outdoor unit carries AHRI Reference No. 217747239 and is rated at 19 SEER2, 12.5 EER2 and 9.5 HSPF2. The system runs on 208/230V 1-Phase power and uses R-32 refrigerant.

What's Included

  • 1 x Daikin 3MXTH24AVJU9 3-port multi-zone outdoor unit
  • 1 x Daikin FTXV09AVJU9 9,000 BTU wall-mounted indoor unit
  • 1 x Daikin FTXV12AVJU9 12,000 BTU wall-mounted indoor unit
  • 2 x wireless remote controller (one packed with each indoor unit)

Line sets, wiring, disconnect and mounting hardware are sold separately.

Key Features

  • 2 independent zones: one indoor unit and remote per room
  • Low ambient heating: heats down to -13°F outdoors
  • Drain pan heater: factory installed to stop ice build-up after defrost
  • Inverter compressor: matches output to the load for steady comfort and lower energy use
  • Slim wall units: Daikin wall-mounted indoor units with quiet fan speeds
  • R-32 refrigerant: lower-GWP refrigerant used across the current Daikin lineup

System Ratings

Outdoor Unit: 3MXTH24AVJU9

Indoor Unit: FTXV09AVJU9 (x1)

Indoor Unit: FTXV12AVJU9 (x1)

Frequently Asked Questions

What is the AHRI rating for this system?

With non-ducted indoor units, the 3MXTH24AVJU9 outdoor unit is rated under AHRI Reference No. 217747239: 19 SEER2, 12.5 EER2, 9.5 HSPF2.

Can I add or swap an indoor unit later?

The 3MXTH24AVJU9 supports up to 3 indoor units. Contact HVAC365 before changing the combination so we can confirm it stays within Daikin's capacity limits.

Who should install it?

Have a licensed HVAC contractor install the system so it runs as designed and stays eligible for the Daikin warranty.

Want a different room combination? Send HVAC365 your room list and we will build a matched system for you.

Documents

White Paper

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
Daikin
Width:
43.31 (in)
Height:
34.25 (in)
Depth:
18.13 (in)
Weight:
251.00 LBS
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Prop 65 Warning:
Yes
Cooling Capacity (BTU):
24,000
Capacity (Tons):
2
Zones:
2
Mount Type:
Wall Mount
System Type:
Heat Pump
SEER2:
19 SEER2
EER2:
12 EER2
HSPF2:
9 HSPF2
Cold Climate:
Yes
Minimum Heating Temp (°F):
-13
Refrigerant Type:
R-32
Electrical Phase:
1-Phase
AHRI Certified:
Yes
AHRI Reference Number:
217747239
Indoor Unit Combination:
9K + 12K
Voltage / Phase:
208/230V 1-Phase
Outdoor Unit 3MXTH24AVJU9 - Nominal Capacity (Tons):
2
Outdoor Unit 3MXTH24AVJU9 - Cooling Capacity (BTU/h):
24,000
Outdoor Unit 3MXTH24AVJU9 - Heating Capacity (BTU/h):
24,000
Outdoor Unit 3MXTH24AVJU9 - Maximum Indoor Units (Zones):
3
Outdoor Unit 3MXTH24AVJU9 - Refrigerant:
R-32
Outdoor Unit 3MXTH24AVJU9 - Voltage/Phase/Hz:
208-230 V / 1 Ph / 60 Hz
Outdoor Unit 3MXTH24AVJU9 - Minimum Circuit Ampacity (MCA):
33.6 A
Outdoor Unit 3MXTH24AVJU9 - Maximum Overcurrent Protection (MOP):
35 A
Outdoor Unit 3MXTH24AVJU9 - Minimum Heating Temp (F):
-13 F
Outdoor Unit 3MXTH24AVJU9 - Sound Level (dB):
55
Outdoor Unit 3MXTH24AVJU9 - Unit Dimensions (W x D x H):
43.31 in x 18.13 in x 34.25 in
Outdoor Unit 3MXTH24AVJU9 - Unit Weight:
213 lb
Outdoor Unit 3MXTH24AVJU9 - Drain Pan Heater:
Factory Installed
Indoor Unit FTXV09AVJU9 - Type:
Wall Mounted
Indoor Unit FTXV09AVJU9 - Nominal Capacity (Tons):
0.75
Indoor Unit FTXV09AVJU9 - Cooling Capacity (BTU/h):
9,000
Indoor Unit FTXV09AVJU9 - Refrigerant:
R-32
Indoor Unit FTXV09AVJU9 - Airflow (CFM):
166-381
Indoor Unit FTXV09AVJU9 - Sound Level (dB):
24-43
Indoor Unit FTXV09AVJU9 - Liquid Line Size:
1/4 in
Indoor Unit FTXV09AVJU9 - Suction Line Size:
3/8 in
Indoor Unit FTXV09AVJU9 - Unit Dimensions (W x D x H):
30.31 in x 8.75 in x 11.25 in
Indoor Unit FTXV09AVJU9 - Unit Weight:
19 lb
Indoor Unit FTXV09AVJU9 - UPC:
647379452384
Indoor Unit FTXV12AVJU9 - Type:
Wall Mounted
Indoor Unit FTXV12AVJU9 - Nominal Capacity (Tons):
1
Indoor Unit FTXV12AVJU9 - Cooling Capacity (BTU/h):
12,000
Indoor Unit FTXV12AVJU9 - Refrigerant:
R-32
Indoor Unit FTXV12AVJU9 - Airflow (CFM):
166-392
Indoor Unit FTXV12AVJU9 - Sound Level (dB):
19-45
Indoor Unit FTXV12AVJU9 - Liquid Line Size:
1/4 in
Indoor Unit FTXV12AVJU9 - Suction Line Size:
3/8 in
Indoor Unit FTXV12AVJU9 - Unit Dimensions (W x D x H):
30.31 in x 8.75 in x 11.25 in
Indoor Unit FTXV12AVJU9 - Unit Weight:
19 lb
Indoor Unit FTXV12AVJU9 - UPC:
647379452391
Wi-Fi Control:
Built-In
System Model:
3MXTH24AVJU9-FTXV09AVJU9-FTXV12AVJU9
Connected Indoor Capacity:
21,000 BTU/h
Minimum Heating Operating Temp:
-13°F
Number of Boxes:
3
Product Line:
Daikin Aurora MXTH
Ports / Maximum Zones:
3
Nominal Capacity:
24,000 BTU/h (2 ton)
Rated Cooling Capacity:
24,000 BTU/h
Rated Heating Capacity (47°F):
24,000 BTU/h
Maximum Connectable Indoor Capacity:
39,000 BTU/h
Outdoor Sound Pressure (dBA, cooling / heating):
55 / 57
Factory Drain Pan Heater:
Yes
Nominal Capacity (Tons):
1
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase
Frequently asked questions
How much cooling does the provide?
It is rated for 24,000 BTU of cooling.
What size is the ?
The is a 2 ton unit.
How many zones does the support?
It supports 2 zone(s).
What is the SEER2 rating of the ?
The is rated at 19 SEER2 SEER2.
What is the HSPF2 heating efficiency of the ?
It is rated at 9 HSPF2 HSPF2.
How cold can it be outside for the to keep heating?
It is rated to heat down to -13 °F outdoors.
What refrigerant does the use?
It uses R-32 refrigerant.
Is the AHRI certified?
Yes. The AHRI reference number is 217747239.
What power supply does the need?
It requires 208/230V 1-Phase power.
Can the be controlled over Wi-Fi?
Built-In.
What warranty comes with the 3MXTH24AVJU9-FTXV09AVJU9-FTXV12AVJU9?
10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase
Who makes the 3MXTH24AVJU9-FTXV09AVJU9-FTXV12AVJU9?
The 3MXTH24AVJU9-FTXV09AVJU9-FTXV12AVJU9 is made by Daikin.
