Daikin 31,000 BTU Wall Mounted Dual Zone Ductless Mini Split Heat Pump Wall 7K + 24K MXM Series

Daikin

5 Star RatingLeave a review

Local HVAC Offers

Special pricing available — add to cart or call for details.
Limited-time availability.
About this promotion
Cyber Weekend Sales Event

No reviews yet Write a Review
SKU:
4MXM36AVJU9-CTXV07AVJU9-FTXV24AVJU9
Your Price $0.00
Detecting ZIP...
Est. Net Incentive Amount: $0.00
We could not detect your ZIP automatically. Enter your ZIP to check incentives.
Available Incentives
$0.00
Selected Incentives
0
Unpriced Programs
0
Estimates assume eligibility; programs and amounts can change.
Learn more about incentives
Daikin Dual Zone System: outdoor unit 4MXM36AVJU9 with 7K + 24K BTU wall-mounted indoor units and wireless remotes
Condition:
New
Width:
34.25 (in)
Height:
29.50 (in)
Depth:
12.63 (in)

Questions about Daikin 31,000 BTU Wall Mounted Dual Zone Ductless Mini Split Heat Pump Wall 7K + 24K MXM Series?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business
View Certification

At a glance

Fast Shipping

Customer Support

Warranty Coverage

Financing Avaliable

$6,437.00
75 in stock • Ships in 2-3 Business Days
Overview

Description

Life at home

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
Daikin
Width:
34.25 (in)
Height:
29.50 (in)
Depth:
12.63 (in)
Weight:
198.00 LBS
AHRI Certified:
Yes
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Breaker Size (Amps):
30
Connection Type:
Flare Fittings
Liquid Line Size | OD - Outside Diameter:
1/4” & 1/4”
Cooling Capacity (BTU):
36,000
Compressor Type:
Inverter
Configuration:
Wall Mount
Indoor Air Handler Type(s):
Wall Mounted
Refrigerant Type:
R-32
Prop 65 Warning:
Yes
Suction Line Size | OD - Outside Diameter:
3/8” & 5/8”
Capacity (Tons):
3
Size:
7+24
SEER2:
20+ SEER2
Zones:
2
Mount Type:
Wall Mount
System Type:
Heat Pump
EER2:
10 EER2
HSPF2:
9 HSPF2
Cold Climate:
No
Minimum Heating Temp (°F):
5
Electrical Phase:
1-Phase
Sound Level Indoor (dB):
24
Sound Level Outdoor (dB):
56
Energy Star Listed:
Yes
Indoor Unit Combination:
7K + 24K
Voltage / Phase:
208/230V 1-Phase
Outdoor Unit 4MXM36AVJU9 - Nominal Capacity (Tons):
3
Outdoor Unit 4MXM36AVJU9 - Cooling Capacity (BTU/h):
36,000
Outdoor Unit 4MXM36AVJU9 - Heating Capacity (BTU/h):
34,600
Outdoor Unit 4MXM36AVJU9 - Maximum Indoor Units (Zones):
4
Outdoor Unit 4MXM36AVJU9 - Refrigerant:
R-32
Outdoor Unit 4MXM36AVJU9 - Voltage/Phase/Hz:
208-230 V / 1 Ph / 60 Hz
Outdoor Unit 4MXM36AVJU9 - Minimum Circuit Ampacity (MCA):
24.1 A
Outdoor Unit 4MXM36AVJU9 - Maximum Overcurrent Protection (MOP):
25 A
Outdoor Unit 4MXM36AVJU9 - Compressor Type:
Inverter Swing Rotary
Outdoor Unit 4MXM36AVJU9 - Minimum Heating Temp (F):
5 F
Outdoor Unit 4MXM36AVJU9 - Sound Level (dB):
56
Outdoor Unit 4MXM36AVJU9 - Liquid Line Size:
1/4 in
Outdoor Unit 4MXM36AVJU9 - Suction Line Size:
3/8 in
Outdoor Unit 4MXM36AVJU9 - Unit Dimensions (W x D x H):
34.25 in x 12.63 in x 29.5 in
Outdoor Unit 4MXM36AVJU9 - Unit Weight:
142 lb
Indoor Unit CTXV07AVJU9 - Type:
Wall Mounted
Indoor Unit CTXV07AVJU9 - Nominal Capacity (Tons):
0.5
Indoor Unit CTXV07AVJU9 - Cooling Capacity (BTU/h):
7,000
Indoor Unit CTXV07AVJU9 - Refrigerant:
R-32
Indoor Unit CTXV07AVJU9 - Airflow (CFM):
166-332
Indoor Unit CTXV07AVJU9 - Sound Level (dB):
24-40
Indoor Unit CTXV07AVJU9 - Liquid Line Size:
1/4 in
Indoor Unit CTXV07AVJU9 - Suction Line Size:
3/8 in
Indoor Unit CTXV07AVJU9 - Unit Dimensions (W x D x H):
30.31 in x 8.75 in x 11.25 in
Indoor Unit CTXV07AVJU9 - Unit Weight:
19 lb
Indoor Unit FTXV24AVJU9 - Type:
Wall Mounted
Indoor Unit FTXV24AVJU9 - Nominal Capacity (Tons):
2
Indoor Unit FTXV24AVJU9 - Cooling Capacity (BTU/h):
24,000
Indoor Unit FTXV24AVJU9 - Refrigerant:
R-32
Indoor Unit FTXV24AVJU9 - Airflow (CFM):
335-629
Indoor Unit FTXV24AVJU9 - Sound Level (dB):
34-52
Indoor Unit FTXV24AVJU9 - Liquid Line Size:
1/4 in
Indoor Unit FTXV24AVJU9 - Suction Line Size:
5/8 in
Indoor Unit FTXV24AVJU9 - Unit Dimensions (W x D x H):
39 in x 10.38 in x 11.63 in
Indoor Unit FTXV24AVJU9 - Unit Weight:
27 lb
Outdoor Unit 4MXM36AVJU9 - UPC:
647379452469
Indoor Unit CTXV07AVJU9 - UPC:
647379452377
Indoor Unit FTXV24AVJU9 - UPC:
647379452421
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase
