Complete system: Daikin 34,000 BTU Wall Mounted Quad Zone Ductless Mini Split Heat Pump Wall 7K + 9K + 9K + 9K MXTH Series with Wi-Fi
UPC:
647379452377
Condition:
New
Width:
43.31 (in)
Height:
34.25 (in)
Depth:
18.13 (in)

Questions about Daikin 34,000 BTU Wall Mounted Quad Zone Ductless Mini Split Heat Pump Wall 7K + 9K + 9K + 9K MXTH Series with Wi-Fi | 4MXTH36AVJU9-1-CTXV07AVJU9-3-FTXV09AVJU9?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business
View Certification

Fast Shipping

Customer Support

Warranty Coverage

Financing Available

$8,854.00
  • Qualifies for FREE Shipping
105 in stock • Ships in 2-3 Business Days
Overview

Daikin 34,000 BTU Wall Mounted Quad Zone Ductless Mini Split Heat Pump Wall 7K + 9K + 9K + 9K MXTH Series with Wi-Fi | 4MXTH36AVJU9-1-CTXV07AVJU9-3-FTXV09AVJU9

Complete system: Daikin 34,000 BTU Wall Mounted Quad Zone Ductless Mini Split Heat Pump Wall 7K + 9K + 9K + 9K MXTH Series with Wi-Fi
Product details

Description

Product Summary

This Daikin Aurora MXTH quad-zone system pairs the 4MXTH36AVJU9 36,000 BTU (3 ton) multi-zone outdoor unit with 4 wall-mounted indoor units (7K + 9K + 9K + 9K). Each room gets its own indoor unit and its own wireless remote, so you can set a different temperature in every zone.

Aurora is Daikin's cold-climate line: the outdoor unit keeps heating down to -13°F and has an anti-corrosion coated coil. This MXTH version adds a factory-installed drain pan heater that keeps defrost water from freezing in the base pan.

With non-ducted indoor units like these, the outdoor unit carries AHRI Reference No. 217747241 and is rated at 20 SEER2, 12 EER2 and 9.5 HSPF2. The system runs on 208/230V 1-Phase power and uses R-32 refrigerant.

What's Included

  • 1 x Daikin 4MXTH36AVJU9 4-port multi-zone outdoor unit
  • 1 x Daikin CTXV07AVJU9 7,000 BTU wall-mounted indoor unit
  • 3 x Daikin FTXV09AVJU9 9,000 BTU wall-mounted indoor unit
  • 4 x wireless remote controller (one packed with each indoor unit)

Line sets, wiring, disconnect and mounting hardware are sold separately.

Key Features

  • 4 independent zones: one indoor unit and remote per room
  • Low ambient heating: heats down to -13°F outdoors
  • Drain pan heater: factory installed to stop ice build-up after defrost
  • Inverter compressor: matches output to the load for steady comfort and lower energy use
  • Slim wall units: Daikin wall-mounted indoor units with quiet fan speeds
  • R-32 refrigerant: lower-GWP refrigerant used across the current Daikin lineup

System Ratings

Outdoor Unit: 4MXTH36AVJU9

Indoor Unit: CTXV07AVJU9 (x1)

Indoor Unit: FTXV09AVJU9 (x3)

Frequently Asked Questions

What is the AHRI rating for this system?

With non-ducted indoor units, the 4MXTH36AVJU9 outdoor unit is rated under AHRI Reference No. 217747241: 20 SEER2, 12 EER2, 9.5 HSPF2.

Can I add or swap an indoor unit later?

The 4MXTH36AVJU9 supports up to 4 indoor units. Contact HVAC365 before changing the combination so we can confirm it stays within Daikin's capacity limits.

Who should install it?

Have a licensed HVAC contractor install the system so it runs as designed and stays eligible for the Daikin warranty.

Want a different room combination? Send HVAC365 your room list and we will build a matched system for you.

Documents

White Paper

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
Daikin
Width:
43.31 (in)
Height:
34.25 (in)
Depth:
18.13 (in)
Weight:
292.00 LBS
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Prop 65 Warning:
Yes
Cooling Capacity (BTU):
36,000
Capacity (Tons):
3
Zones:
4
Mount Type:
Wall Mount
System Type:
Heat Pump
SEER2:
20+ SEER2
EER2:
12 EER2
HSPF2:
9 HSPF2
Cold Climate:
Yes
Minimum Heating Temp (°F):
-13
Refrigerant Type:
R-32
Electrical Phase:
1-Phase
AHRI Certified:
Yes
AHRI Reference Number:
217747241
Indoor Unit Combination:
7K + 9K + 9K + 9K
Voltage / Phase:
208/230V 1-Phase
Outdoor Unit 4MXTH36AVJU9 - Nominal Capacity (Tons):
3
Outdoor Unit 4MXTH36AVJU9 - Cooling Capacity (BTU/h):
34,400
Outdoor Unit 4MXTH36AVJU9 - Heating Capacity (BTU/h):
33,200
Outdoor Unit 4MXTH36AVJU9 - Maximum Indoor Units (Zones):
4
Outdoor Unit 4MXTH36AVJU9 - Refrigerant:
R-32
Outdoor Unit 4MXTH36AVJU9 - Voltage/Phase/Hz:
208-230 V / 1 Ph / 60 Hz
Outdoor Unit 4MXTH36AVJU9 - Minimum Circuit Ampacity (MCA):
37.5 A
Outdoor Unit 4MXTH36AVJU9 - Maximum Overcurrent Protection (MOP):
40 A
Outdoor Unit 4MXTH36AVJU9 - Minimum Heating Temp (F):
-13 F
Outdoor Unit 4MXTH36AVJU9 - Sound Level (dB):
55
Outdoor Unit 4MXTH36AVJU9 - Unit Dimensions (W x D x H):
43.31 in x 18.13 in x 34.25 in
Outdoor Unit 4MXTH36AVJU9 - Unit Weight:
216 lb
Outdoor Unit 4MXTH36AVJU9 - Drain Pan Heater:
Factory Installed
Indoor Unit CTXV07AVJU9 - Type:
Wall Mounted
Indoor Unit CTXV07AVJU9 - Nominal Capacity (Tons):
0.5
Indoor Unit CTXV07AVJU9 - Cooling Capacity (BTU/h):
7,000
Indoor Unit CTXV07AVJU9 - Refrigerant:
R-32
Indoor Unit CTXV07AVJU9 - Airflow (CFM):
166-332
Indoor Unit CTXV07AVJU9 - Sound Level (dB):
24-40
Indoor Unit CTXV07AVJU9 - Liquid Line Size:
1/4 in
Indoor Unit CTXV07AVJU9 - Suction Line Size:
3/8 in
Indoor Unit CTXV07AVJU9 - Unit Dimensions (W x D x H):
30.31 in x 8.75 in x 11.25 in
Indoor Unit CTXV07AVJU9 - Unit Weight:
19 lb
Indoor Unit CTXV07AVJU9 - UPC:
647379452377
Indoor Unit FTXV09AVJU9 - Type:
Wall Mounted
Indoor Unit FTXV09AVJU9 - Nominal Capacity (Tons):
0.75
Indoor Unit FTXV09AVJU9 - Cooling Capacity (BTU/h):
9,000
Indoor Unit FTXV09AVJU9 - Refrigerant:
R-32
Indoor Unit FTXV09AVJU9 - Airflow (CFM):
166-381
Indoor Unit FTXV09AVJU9 - Sound Level (dB):
24-43
Indoor Unit FTXV09AVJU9 - Liquid Line Size:
1/4 in
Indoor Unit FTXV09AVJU9 - Suction Line Size:
3/8 in
Indoor Unit FTXV09AVJU9 - Unit Dimensions (W x D x H):
30.31 in x 8.75 in x 11.25 in
Indoor Unit FTXV09AVJU9 - Unit Weight:
19 lb
Indoor Unit FTXV09AVJU9 - UPC:
647379452384
Wi-Fi Control:
Built-In
System Model:
4MXTH36AVJU9-1-CTXV07AVJU9-3-FTXV09AVJU9
Connected Indoor Capacity:
34,000 BTU/h
Minimum Heating Operating Temp:
-13°F
Number of Boxes:
5
Product Line:
Daikin Aurora MXTH
Ports / Maximum Zones:
4
Nominal Capacity:
36,000 BTU/h (3 ton)
Rated Cooling Capacity:
34,400 BTU/h
Rated Heating Capacity (47°F):
33,200 BTU/h
Maximum Connectable Indoor Capacity:
48,000 BTU/h
Outdoor Sound Pressure (dBA, cooling / heating):
55 / 57
Factory Drain Pan Heater:
Yes
Nominal Capacity (Tons):
0.5
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase
Frequently asked questions
How much cooling does the provide?
It is rated for 36,000 BTU of cooling.
What size is the ?
The is a 3 ton unit.
How many zones does the support?
It supports 4 zone(s).
What is the SEER2 rating of the ?
The is rated at 20+ SEER2 SEER2.
What is the HSPF2 heating efficiency of the ?
It is rated at 9 HSPF2 HSPF2.
How cold can it be outside for the to keep heating?
It is rated to heat down to -13 °F outdoors.
What refrigerant does the use?
It uses R-32 refrigerant.
Is the AHRI certified?
Yes. The AHRI reference number is 217747241.
What power supply does the need?
It requires 208/230V 1-Phase power.
Can the be controlled over Wi-Fi?
Built-In.
What warranty comes with the 4MXTH36AVJU9-1-CTXV07AVJU9-3-FTXV09AVJU9?
10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase
Who makes the 4MXTH36AVJU9-1-CTXV07AVJU9-3-FTXV09AVJU9?
The 4MXTH36AVJU9-1-CTXV07AVJU9-3-FTXV09AVJU9 is made by Daikin.
