Description
Product Summary
This Daikin Aurora MXTH quad-zone system pairs the 4MXTH36AVJU9 36,000 BTU (3 ton) multi-zone outdoor unit with 4 wall-mounted indoor units (7K + 7K + 7K + 15K). Each room gets its own indoor unit and its own wireless remote, so you can set a different temperature in every zone.
Aurora is Daikin's cold-climate line: the outdoor unit keeps heating down to -13°F and has an anti-corrosion coated coil. This MXTH version adds a factory-installed drain pan heater that keeps defrost water from freezing in the base pan.
With non-ducted indoor units like these, the outdoor unit carries AHRI Reference No. 217747241 and is rated at 20 SEER2, 12 EER2 and 9.5 HSPF2. The system runs on 208/230V 1-Phase power and uses R-32 refrigerant.
What's Included
- 1 x Daikin 4MXTH36AVJU9 4-port multi-zone outdoor unit
- 3 x Daikin CTXV07AVJU9 7,000 BTU wall-mounted indoor unit
- 1 x Daikin FTXV15AVJU9 15,000 BTU wall-mounted indoor unit
- 4 x wireless remote controller (one packed with each indoor unit)
Line sets, wiring, disconnect and mounting hardware are sold separately.
Key Features
- 4 independent zones: one indoor unit and remote per room
- Low ambient heating: heats down to -13°F outdoors
- Drain pan heater: factory installed to stop ice build-up after defrost
- Inverter compressor: matches output to the load for steady comfort and lower energy use
- Slim wall units: Daikin wall-mounted indoor units with quiet fan speeds
- R-32 refrigerant: lower-GWP refrigerant used across the current Daikin lineup
System Ratings
| System Model | 4MXTH36AVJU9-3-CTXV07AVJU9-1-FTXV15AVJU9 |
|---|---|
| Indoor Unit Combination | 7K + 7K + 7K + 15K |
| Connected Indoor Capacity | 36,000 BTU/h |
| AHRI Reference No. (non-ducted) | 217747241 |
| SEER2 | 20 |
| EER2 | 12 |
| HSPF2 | 9.5 |
| Minimum Heating Operating Temp | -13°F |
| Power Supply | 208/230V 1-Phase, 60 Hz |
| Refrigerant | R-32 |
| Number of Boxes | 5 |
Outdoor Unit: 4MXTH36AVJU9
| Series | Daikin Aurora MXTH |
|---|---|
| Ports / Maximum Zones | 4 |
| Nominal Capacity | 36,000 BTU/h (3 ton) |
| Rated Cooling Capacity | 34,400 BTU/h |
| Rated Heating Capacity (47°F) | 33,200 BTU/h |
| Maximum Connectable Indoor Capacity | 48,000 BTU/h |
| MCA / MOP | 37.5 A / 40 A |
| Outdoor Sound Pressure (dBA, cooling / heating) | 55 / 57 |
| Factory Drain Pan Heater | Yes |
| Unit Dimensions (W x H x D) | 43-5/16 x 34-1/4 x 18-1/8 in |
| Unit Net Weight | 216 lb |
Indoor Unit: CTXV07AVJU9 (x3)
| Type | Wall Mounted |
|---|---|
| Nominal Capacity (Tons) | 0.5 |
| Cooling Capacity (BTU/h) | 7,000 |
| Refrigerant | R-32 |
| Airflow (CFM) | 166-332 |
| Sound Level (dB) | 24-40 |
| Liquid Line Size | 1/4 in |
| Suction Line Size | 3/8 in |
| Unit Dimensions (W x D x H) | 30.31 in x 8.75 in x 11.25 in |
| Unit Weight | 19 lb |
| UPC | 647379452377 |
Indoor Unit: FTXV15AVJU9 (x1)
| Type | Wall Mounted |
|---|---|
| Nominal Capacity (Tons) | 1.25 |
| Cooling Capacity (BTU/h) | 15,000 |
| Refrigerant | R-32 |
| Airflow (CFM) | 339-540 |
| Sound Level (dB) | 33-45 |
| Liquid Line Size | 1/4 in |
| Suction Line Size | 1/2 in |
| Unit Dimensions (W x D x H) | 39 in x 10.38 in x 11.63 in |
| Unit Weight | 27 lb |
| UPC | 647379452407 |
Frequently Asked Questions
What is the AHRI rating for this system?
With non-ducted indoor units, the 4MXTH36AVJU9 outdoor unit is rated under AHRI Reference No. 217747241: 20 SEER2, 12 EER2, 9.5 HSPF2.
Can I add or swap an indoor unit later?
The 4MXTH36AVJU9 supports up to 4 indoor units. Contact HVAC365 before changing the combination so we can confirm it stays within Daikin's capacity limits.
Who should install it?
Have a licensed HVAC contractor install the system so it runs as designed and stays eligible for the Daikin warranty.
Want a different room combination? Send HVAC365 your room list and we will build a matched system for you.
