Goodman 2 Ton 17.2 SEER2 8.1 HSPF2 80% AFUE 60,000 BTU Hybrid Dual Fuel Heat Pump & Gas Furnace Split System Upflow R-32 | GLZT7CA2410 GRVT800603BX CAPTA3026B3

Goodman

Local HVAC Offers

Special pricing available — add to cart or call for details.
Limited-time availability.
About this promotion
Cyber Weekend Sales Event

No reviews yet Write a Review
SKU:
GLZT7CA2410-GRVT800603BX-CAPTA3026B3
Your Price $0.00
Detecting ZIP...
Est. Net Incentive Amount: $0.00
We could not detect your ZIP automatically. Enter your ZIP to check incentives.
Available Incentives
$0.00
Selected Incentives
0
Unpriced Programs
0
Estimates assume eligibility; programs and amounts can change.
Learn more about incentives
Goodman 2 Ton Heat Pump & Gas Furnace Dual Fuel System: GLZT7CA2410, CAPTA3026B3, GRVT800603BX
Condition:
New
Width:
35.50 (in)
Height:
39.50 (in)
Depth:
35.50 (in)

Questions about Goodman 2 Ton 17.2 SEER2 8.1 HSPF2 80% AFUE 60,000 BTU Hybrid Dual Fuel Heat Pump & Gas Furnace Split System Upflow R-32 | GLZT7CA2410 GRVT800603BX CAPTA3026B3?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business
View Certification

At a glance

Fast Shipping

Customer Support

Warranty Coverage

Financing Avaliable

$7,220.00
45 in stock • Ships in 2-3 Business Days

Description

The Goodman 2 Ton 17.2 SEER2 8.1 HSPF2 80% AFUE 60,000 BTU Hybrid Dual Fuel Heat Pump & Gas Furnace Split System Upflow R-32 (GLZT7CA2410 / GRVT800603BX / CAPTA3026B3) is a complete dual fuel heating and cooling system that pairs an electric heat pump with a gas furnace. This AHRI-matched system combines a 2-ton R-32 heat pump, 80% AFUE two-stage gas furnace, and cased evaporator coil so the heat pump handles cooling and mild-weather heating, while the furnace takes over when outdoor temperatures drop.

Designed for upflow installation, the system uses the furnace's variable-speed ECM blower motor to move air for both the heat pump and the gas burners. With a dual-fuel thermostat or outdoor temperature control, the system switches to gas heat below a set balance point, which keeps homes comfortable in cold snaps and lets you choose the more economical fuel for your local utility rates.

Key Features

  • 2 Ton Cooling Capacity – AHRI-rated 23,800 BTU/h of cooling

  • 17.2 SEER2 / 12.5 EER2 – Certified matched-system cooling efficiency

  • 8.1 HSPF2 Heat Pump Heating – 23,600 BTU/h at 47°F and 14,000 BTU/h at 17°F

  • 60,000 BTU Gas Furnace – Two-stage heating with 80% AFUE efficiency

  • Dual Fuel Operation – Heat pump for efficient mild-weather heat, gas furnace for cold-weather backup

  • Upflow R-32 System – Uses lower-GWP R-32 refrigerant

System Components Included

  • Goodman GLZT7CA2410 2 Ton R-32 Heat Pump

  • Goodman GRVT800603BX 60,000 BTU 80% AFUE Two-Stage Gas Furnace

  • Goodman CAPTA3026B3 Cased Upflow/Downflow R-32 Evaporator Coil

Compatibility & Installation Notes

The GLZT7CA2410 / GRVT800603BX / CAPTA3026B3 system is AHRI certified under reference number 216617587 and is designed for residential upflow applications. Compatibility with the property's ductwork, electrical service, gas supply, refrigerant lines, condensate drainage, and furnace venting must be confirmed before installation. The communicating GLZT7CA2410 heat pump and GRVT800603BX furnace connect over the two communication wires, and the furnace control manages dual fuel switchover on its own, so a standard single-stage 24 VAC thermostat is all you need. No separate dual fuel kit is required.

Specifications

  • System Type: Hybrid Dual Fuel Heat Pump & Gas Furnace Split System

  • AHRI Reference Number: 216617587

  • Cooling Capacity: 23,800 BTU/h

  • Heat Pump Heating Capacity: 23,600 BTU/h at 47°F / 14,000 BTU/h at 17°F

  • Cooling Efficiency: 17.2 SEER2 / 12.5 EER2

  • Heating Efficiency: 8.1 HSPF2

  • Furnace Input / Output: 60,000 / 48,000 BTU/h

  • Furnace Efficiency: 80% AFUE

  • Refrigerant / Orientation: R-32 / Upflow

Installation Notes

  • Verify compatibility with the existing upflow ductwork

  • Confirm electrical service and natural gas connection requirements

  • Check the required refrigerant line sizes before installation

  • Ensure proper metal flue venting (Category I) for the 80% AFUE furnace

  • Connect the 1 and 2 communication wires between the furnace and heat pump and set up the thermostat for single-stage AC and single-stage gas heat

  • Installation should be completed by a qualified HVAC professional

Frequently Asked Questions

What is included in this Goodman HVAC system?

The package includes the GLZT7CA2410 heat pump, GRVT800603BX gas furnace, and CAPTA3026B3 cased evaporator coil.

How does a dual fuel system work?

The heat pump cools in summer and heats in mild weather. When the outdoor temperature falls below the balance point set on the thermostat, the gas furnace takes over heating, so the system always runs on the more effective heat source.

What is the heating rating of the heat pump?

This matched system is rated at 8.1 HSPF2, with 23,600 BTU/h of heat pump heating at 47°F.

What is the cooling capacity of this system?

The system provides 2 tons with an AHRI-rated 23,800 BTU/h of cooling.

Is the furnace single-stage or two-stage?

The Goodman GRVT800603BX is a two-stage gas furnace.

What does 80% AFUE mean?

It means approximately 80% of the furnace's fuel is converted into usable heating energy.

Does this system use R-32 refrigerant?

Yes. The heat pump and evaporator coil are designed for R-32 refrigerant.

White Paper

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
Goodman
Width:
35.50 (in)
Height:
39.50 (in)
Depth:
35.50 (in)
Weight:
386.00 LBS
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
AHRI Certified:
Yes
Capacity (Tons):
2
Product Category:
Hybrid Dual Fuel Split System
Configuration:
Upflow
Cabinet Width (in):
17.5
AHRI Reference Number:
216617587
Color:
Gray
AFUE:
80%
Blower Motor Type:
ECM Variable Speed
Heating Stages:
Two Stage
EER2:
12 EER2
Electrical Frequency:
60 Hz
Electrical Phase:
1-Phase
Liquid Line Size:
3/8 in
Suction Line Size:
3/4 in
Line Set Connection Type:
Braze
Input (BTU):
60,000
Prop 65 Warning:
Yes
SEER2:
17 SEER2
HSPF2:
8 HSPF2
Refrigerant Type:
R-32
Vent Type:
Chimney / Category I
Cooling Capacity (BTU):
24,000
Heating Capacity (BTU):
24,000
DOE Regional Compliance:
Nationwide
Compressor Stages:
Two Stage
Voltage / Phase:
208/230V 1-Phase
Shipping Weight:
151 lb
Heat Pump GLZT7CA2410 - Nominal Capacity (Tons):
2
Heat Pump GLZT7CA2410 - Cooling Capacity (BTU/h):
24,000
Heat Pump GLZT7CA2410 - Heating Capacity (BTU/h):
24,000
Heat Pump GLZT7CA2410 - Refrigerant:
R-32
Heat Pump GLZT7CA2410 - Voltage/Phase/Hz:
208-230 V / 1 Ph
Heat Pump GLZT7CA2410 - Minimum Circuit Ampacity (MCA):
15.0 A
Heat Pump GLZT7CA2410 - Maximum Overcurrent Protection (MOP):
20 A
Heat Pump GLZT7CA2410 - Compressor Type:
Scroll
Heat Pump GLZT7CA2410 - Compressor Stages:
Two Stage
Heat Pump GLZT7CA2410 - Liquid Line Size:
3/8 in
Heat Pump GLZT7CA2410 - Suction Line Size:
3/4 in
Heat Pump GLZT7CA2410 - Sound Level (dB):
72
Heat Pump GLZT7CA2410 - UPC:
663051747654
Furnace GRVT800603BX - Input (BTU/h):
60,000
Furnace GRVT800603BX - Output (BTU/h):
48,000
Furnace GRVT800603BX - AFUE:
80%
Furnace GRVT800603BX - Heating Stages:
Two Stage
Furnace GRVT800603BX - Blower Motor Type:
ECM Variable Speed
Furnace GRVT800603BX - Maximum Cooling Capacity (Tons):
3
Furnace GRVT800603BX - Configuration:
Upflow/Horizontal
Furnace GRVT800603BX - Cabinet Width:
17.5 in
Furnace GRVT800603BX - Vent Type:
Chimney / Category I
Furnace GRVT800603BX - Gas Type:
Propane Convertible
Furnace GRVT800603BX - Voltage/Phase/Hz:
115 V / 1 Ph / 60 Hz
Furnace GRVT800603BX - Unit Dimensions (W x D x H):
17.5 in x 28 in x 33.375 in
Furnace GRVT800603BX - Shipping Weight:
105 lb
Evaporator Coil CAPTA3026B3 - Nominal Capacity (Tons):
2.5
Evaporator Coil CAPTA3026B3 - Cased/Uncased:
Cased
Evaporator Coil CAPTA3026B3 - Configuration:
Upflow/Downflow
Evaporator Coil CAPTA3026B3 - Cabinet Width:
17.5 in
Evaporator Coil CAPTA3026B3 - Metering Device:
TXV
Evaporator Coil CAPTA3026B3 - Refrigerant:
R-32
Evaporator Coil CAPTA3026B3 - Liquid Line Size:
3/8 in
Evaporator Coil CAPTA3026B3 - Suction Line Size:
3/4 in
Evaporator Coil CAPTA3026B3 - UPC:
663051688384
Dual Fuel Control:
Built-In (Communicating Furnace Control)

Warranty Information

10 Years Heat Exchanger & 10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase

Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.
