Description
Product Summary
The NAVAC NTE11H is a hydraulic tube expander kit for swaging large-diameter soft copper from 3/8" through 1-1/8" O.D. Hydraulic force multiplies hand effort so larger sizes expand cleanly with far less strain than a mechanical lever tool.
A vacuum-sealed hydraulic system never needs an oil change, and the compact body works in tight spaces with one-hand operation. Coverage extends to 1-1/4" through 1-5/8" with the optional NAVAC NTEHHK expander head kit.
Key Features
- Hydraulic Power: Hydraulic action reduces the effort needed to expand large copper.
- Sealed System: Vacuum-sealed hydraulics with no oil changes required.
- 7 Expander Heads: Covers 3/8", 1/2", 5/8", 3/4", 7/8", 1" and 1-1/8" O.D.
- Expandable Range: Optional NTEHHK kit adds 1-1/4", 1-3/8", 1-1/2" and 1-5/8" heads.
- Compact Body: Fits narrow chases and crowded equipment pads.
- One-Hand Operation: Frees the other hand to hold and align tubing.
- Complete Kit: Includes tube cutter, deburring tool and carrying case.
Specifications
| Brand | NAVAC |
|---|---|
| Model | NTE11H |
| Type | Hydraulic Tube Expander |
| Tubing Type | Soft copper |
| Tube O.D. | 3/8", 1/2", 5/8", 3/4", 7/8", 1", 1-1/8" |
| Optional Sizes | 1-1/4", 1-3/8", 1-1/2", 1-5/8" (NTEHHK, sold separately) |
| Hydraulic System | Vacuum sealed, no oil change |
| Power Source | Manual (hydraulic) |
| Package Dimensions | 15" x 10.9" x 2.8" |
| Package Weight | 8.2 lb |
| Warranty | 2 years |
What's Included
- (1) NTE11H hydraulic tube expander
- (7) Expander heads: 3/8" to 1-1/8"
- (1) NTC12 tube cutter (1/8" to 1-1/4")
- (1) NTD28 deburring tool
- (1) Carrying case
Compatibility
Accepts the NAVAC NTEHHK expander head kit for 1-1/4" to 1-5/8" O.D. NTE11H heads also fit the NAVAC NTE11L power expander with the NAQA1 adapter.
Ideal Applications
- Large-diameter refrigerant piping on commercial AC and refrigeration
- Swaging suction lines without couplings
- Service work where a no-battery expander is preferred
- Tight mechanical spaces requiring one-hand operation
