Description
Overview
The Tosot Aoraki 24,000 BTU floor/ceiling mount mini split is a complete single-zone heat pump system: indoor unit, inverter outdoor unit, remote and installation package. It uses a high-efficiency inverter compressor, runs on 208/230V single-phase power and uses R32 refrigerant.
Floor/ceiling units can be mounted low on a wall or under the ceiling, which works well in rooms with angled ceilings, glass walls or limited wall space.
Key Features
- Commercial-grade airflow: High-CFM indoor sections for large rooms, open plans, shops and offices.
- DC inverter compressor: Smooth, efficient capacity control with R32 refrigerant.
- Wi-Fi control: TOSOT+ app control and scheduling.
- Built-in safety: Refrigerant leak detection and condensate overflow protection where equipped.
- Wide operating range: Reliable cooling and heating across extreme outdoor temperatures.
- Up to 22.5 SEER2 & 9.5 HSPF2 with R32 Refrigerant
- ENERGY STAR Certified with tax rebate eligibility
- Flexible Floor or Ceiling Installation for versatile space-saving placement
- Ultra-slim 9.25" Indoor Unit for spaces with limited wall area
- Operates in Extreme Temperatures from -40°F to 140°F
Performance & Efficiency
Capacity is matched to the room size listed below. The inverter compressor ramps up quickly to reach the setpoint, then slows down to hold it, which avoids the on/off cycling of single-speed equipment and cuts power use.
Comfort & Control
Every indoor unit includes a wireless remote, and the TOSOT+ app adds Wi-Fi control, scheduling and voice control through Alexa or Google Home. Sleep, quiet and turbo modes, auto restart after a power outage and a dehumidification (dry) mode are built in.
Specifications
System Performance
| Cooling Capacity | 22,000 Btu/h |
|---|---|
| Heating Capacity | 24,000 Btu/h |
| EER | 3.7 W/W |
| COP | 3.85 W/W |
| SEER2 | 22.5 |
| HSPF2 | 9.5 |
| Airflow(SL) | 1050 CFM |
| Dehumidification | 4.23 Pts/hr |
| Voltage | 208/230V, 60Hz, 1Ph |
| Temperature Setting Range | 61–86°F |
| Rated Power of Cooling | 1743.2 W |
| Rated Power of Heating | 1827 W |
| Rated Current of Cooling | 8.6 A |
| Rated Current of Heating | 9.0 A |
| Rated Power Max. | 3700 W |
| Rated Current | 16 A |
| Min. Current (MCA) | 22 A |
| Max. Over Current Protection | 30 A |
| Energy Star & UL Certified | Yes |
| Lowest Noise Level | 37 dB(A) |
| Refrigerant | R32 |
Indoor Unit (Floor / Ceiling)
| Approximate Shipping Weight | 84.9 lbs |
|---|---|
| Approximate Net Weight | 72.75 lbs |
| Shipping Dimensions (W × H × D) | 53.543x30.197x11.22 in |
| Unit Dimensions (W × H × D) | 47.244x9.252x26.181 in |
Outdoor Unit
| Approximate Net Weight | 103.6 lbs |
|---|---|
| Approximate Shipping Weight | 114.7 lbs |
| Shipping Dimensions (W × H × D) | 42.9x20.7x31.0 in |
| Unit Dimensions (W × H × D) | 37.7x26x15.8 in |
Line Set & Piping
| Copper Line Set Length | 16 ft |
|---|---|
| Max. Line Set Length | 131.2 ft |
| Copper Line Set Size | 1/4" & 5/8" |
| Max. Height Difference | 82 ft |
What's Included
- Indoor unit
- Outdoor unit
- Wireless remote controller
- 16 ft pre-flared copper line set, signal cable and power cord
Installation
Professional installation by a licensed HVAC technician is recommended to protect performance and warranty coverage. Plan the indoor unit location, line set route, condensate drain and a dedicated electrical circuit before ordering.
Frequently Asked Questions
Is this a heat pump?
Yes. It provides both cooling and heating.
What warranty does it carry?
Tosot covers the system for 5 years.
Can I control it from my phone?
Yes. The TOSOT+ app provides Wi-Fi control, schedules and voice control with Alexa and Google Home.
