Description
The Bard W30HF-A00 is a WH Series wall-mount, single-stage heat pump built for commercial and institutional use where you want a durable packaged solution with predictable servicing and a consistent footprint. It’s a common choice for modular buildings, classrooms, portable structures, offices, and support spaces where roof access is undesirable and interior mechanical room space is limited. W30HF-A00 is also frequently purchased by exact model number in like-for-like replacement scenarios, which is how most facilities teams manage this category.
In the certified performance table, W30HF is listed at 29,400 BTUH cooling capacity with 11.4 EER. Heating capacity is listed at 27,000 BTUH with 3.4 COP. These ratings help position the W30HF-A00 as a balanced wall-mount heat pump option for buyers needing both cooling and heat in a single packaged platform.
WH Series standard controls include high and low pressure switches, a compressor control module, and the RDS refrigerant leak detector. For electrical planning, the W30HF-A00 configuration is 230/208V single-phase with lug connections, and the table lists the required MCA and MOCP for this “00” heater option configuration.
Key Features
-
Bard W30HF-A00 wall-mount heat pump: Packaged cooling and heating in one exterior-mounted system
-
Certified cooling performance: 29,400 BTUH; 11.4 EER
-
Certified heating performance: 27,000 BTUH; 3.4 COP
-
Electrical (A00 configuration): 230/208V, 1 phase; MCA 22; MOCP 25; lug connections
-
Standard protection controls: High/low pressure switches and compressor control module
-
Standard refrigerant leak safety: RDS refrigerant leak detector included
-
Electric heat ready (optional): Heater packages available depending on job requirements
