Description
The Bard W42HF-A00 is a WH Series wall-mount, single-stage heat pump built for heavier commercial comfort loads in a packaged exterior-mounted format. It’s a strong fit for modular campuses, schools, telecom shelters, equipment rooms, and light industrial support spaces where footprint control and service access are priorities. W42HF-A00 is often purchased by exact model number in standardized building programs, which helps keep maintenance routines and replacement planning consistent.
In the WH Series certified ratings, W42HF is listed at 41,500 BTUH cooling capacity with 11.4 EER. Heating capacity is listed at 38,000 BTUH with 3.3 COP. These values help position the W42HF-A00 for buyers who need a wall-mount heat pump platform with real capacity for larger zones while staying within a single-stage packaged architecture.
For control protection and safety, WH Series units include standard high and low pressure switches, a compressor control module, and an RDS refrigerant leak detector. Electrical planning for the W42HF-A00 “A00” configuration is 230/208V single-phase with lug connections, and the heater wiring table provides the MCA and MOCP for the “00” configuration.
Key Features
-
Bard W42HF-A00 wall-mount heat pump: Packaged cooling and heating in one exterior-mounted system
-
Certified cooling performance: 41,500 BTUH; 11.4 EER
-
Certified heating performance: 38,000 BTUH; 3.3 COP
-
Electrical (A00 configuration): 230/208V, 1 phase; MCA 31; MOCP 35; lug connections
-
Standard protection controls: High/low pressure switches and compressor control module
-
Standard refrigerant leak safety: RDS refrigerant leak detector included
-
Electric heat ready (optional): Heater packages available depending on job requirements
