Comfortstar BAH17 2 Ton 14.3 SEER2 Heat Pump Split System with Multi-Position Air Handler with ECM Motor R32 | BAH17-24-15 LUC17-24-15

Comfortstar

5 Star RatingLeave a review
No reviews yet Write a Review
SKU:
BAH17-24-15-LUC17-24-15
Your Price $0.00

Detecting ZIP...
Est. Net Incentive Amount: $0.00
We could not detect your ZIP automatically. Enter your ZIP to check incentives.
Available Incentives
$0.00
Selected Incentives
0
Unpriced Programs
0
Estimates assume eligibility; programs and amounts can change.
Condition:
New
Width:
17.50 (in)
Height:
45.00 (in)
Depth:
21.00 (in)

Questions about Comfortstar BAH17 2 Ton 14.3 SEER2 Heat Pump Split System with Multi-Position Air Handler with ECM Motor R32 | BAH17-24-15 LUC17-24-15?

Contact us for advice or additional information; our product specialists are here to help!

SupplierGateway® Certified i
Minority-Owned • Small Business

Fast Shipping

Customer Support

Warranty Coverage

Financing Available

$2,955.56

  • Qualifies for FREE Shipping
25 in stock • Ships in 1-2 Business Days
Overview

Comfortstar BAH17 2 Ton 14.3 SEER2 Heat Pump Split System with Multi-Position Air Handler with ECM Motor R32 | BAH17-24-15 LUC17-24-15

Comfortstar BAH17 2 Ton 14.3 SEER2 Heat Pump Split System with Multi-Position Air Handler with ECM Motor R32
Product details

Description

Comfortstar BAH17 2 Ton Heat Pump Split System (BAH17-24-15 + LUC17-24-15)

This is a complete, AHRI matched heat pump system from Comfortstar: the BAH17-24-15 top-discharge heat pump and the LUC17-24-15 multi-position air handler, running on R-32. Together they are rated at 23,000 BTU/h cooling, 23,000 BTU/h heating, 14.3 SEER2 and 11.7 EER2 with 7.5 HSPF2 under AHRI certificate 218396750.

The outdoor unit is a straightforward single-stage rotary heat pump: fewer parts, simple 24V controls and easy service. It heats down to -4°F and still delivers about 12,000 BTU/h at 5°F, which covers the vast majority of the country without backup heat in mild climates.

Indoors, the LUC17-24-15 installs upflow, downflow or horizontal, so it works in closets, attics and crawl spaces. Its ECM blower moves up to 650 CFM and the system runs on a standard 24V heat pump thermostat, so no proprietary controls are required.

Heat Pump: BAH17-24-15 Specifications

  • Nominal Capacity (Tons): 2
  • Rated Cooling Capacity (BTU/h): 23,000
  • Rated Heating Capacity @ 47°F (BTU/h): 23,000
  • Heating Capacity @ 5°F (BTU/h): 12,000
  • Compressor: Single-Stage Rotary
  • Discharge: Top
  • Refrigerant: R-32
  • Voltage/Phase/Hz: 208-230 V / 1 Ph / 60 Hz
  • MCA / MOP: 20 A / 25 A
  • Liquid / Suction Line: 3/8" / 3/4"
  • Max Line Length: 131 ft (pre-charged for 25 ft)
  • Operating Range: Cooling 23°F to 125.6°F / Heating -4°F to 86°F
  • Sound Level: 58 dBA
  • Dimensions (W x D x H): 23 5/8" x 23 5/8" x 25"
  • Net / Shipping Weight: 119 lb / 126 lb

Air Handler: LUC17-24-15 Specifications

  • Configuration: Multi-Position
  • Blower Motor: ECM
  • Airflow (CFM, high to low): 650 / 420
  • Refrigerant: R-32
  • Voltage/Phase/Hz: 208-230 V / 1 Ph / 60 Hz
  • MCA / MOP (without heat): 3.5 A / 6 A
  • Electric Heat: Field-installed heat strip, sold separately
  • Dimensions (W x D x H): 17 33/64" x 21 1/32" x 45"
  • Net Weight: 114 lb

System Ratings

  • AHRI Reference Number: 218396750
  • SEER2: 14.3
  • EER2: 11.7
  • HSPF2: 7.5

Both units ship separately. Line set, thermostat, disconnect, condenser pad, filter and electric heat strip are sold separately. Installation and service require a licensed HVAC technician.

Comfort for the people who live there

The right equipment keeps the rooms you live in steady and quiet, whether it's dinner in the kitchen or a weekend project in the garage.

Specifications

Extra Information

Find your comfort-ready size with confidence

Get a fast, learning-friendly estimate for tons and BTUs, then review it with a Pro to dial in the perfect fit for your home.

Brand:
Comfortstar
Width:
17.50 (in)
Height:
45.00 (in)
Depth:
21.00 (in)
Weight:
253.00 LBS
AHRI Certified:
Yes
AHRI Reference Number:
218396750
Refrigerant Type:
R-32
Capacity (Tons):
2
Cooling Capacity (BTU):
23,000
Heating Output (BTU):
20,000 - 29,000 BTU
SEER2:
14 SEER2
EER2:
11 EER2
HSPF2:
7 HSPF2
Product Category:
Heat Pump Split System
Product Line:
BAH17
Outdoor Unit Model:
BAH17-24-15
Air Handler Model:
LUC17-24-15
Compressor Stages:
Single Stage
Discharge:
Top
Electrical Phase:
1-Phase
Voltage / Phase:
208/230V 1-Phase
Matched Indoor Type:
Air Handler
Configuration:
Multi-Position
Blower Motor Type:
ECM
DOE Regional Compliance:
Nationwide
Electric Heat Options:
Field-installed heat strip, sold separately
System Type:
Heat Pump
Operating Mode:
Cooling & Heating
Max Line Length:
131 ft
Prop 65 Warning:
Yes
Safety Information:
⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Heat Pump BAH17-24-15 - Compressor:
Single-Stage Rotary
Heat Pump BAH17-24-15 - Discharge:
Top
Heat Pump BAH17-24-15 - MCA / MOP:
20 A / 25 A
Heat Pump BAH17-24-15 - Liquid / Suction Line:
3/8" / 3/4"
Heat Pump BAH17-24-15 - Sound Level (dBA):
58
Heat Pump BAH17-24-15 - Dimensions (W x D x H):
23 5/8" x 23 5/8" x 25"
Heat Pump BAH17-24-15 - Net / Shipping Weight:
119 lb / 126 lb
Air Handler LUC17-24-15 - Configuration:
Multi-Position
Air Handler LUC17-24-15 - Blower Motor:
ECM
Air Handler LUC17-24-15 - Airflow (CFM, high to low):
650 / 420
Air Handler LUC17-24-15 - Sound Level (dBA):
38.5/34
Air Handler LUC17-24-15 - MCA / MOP (without heat):
3.5 A / 6 A
Air Handler LUC17-24-15 - Dimensions (W x D x H):
17 33/64" x 21 1/32" x 45"
Air Handler LUC17-24-15 - Net Weight:
114 lb / 127 lb shipping
Please Note: To validate the manufacturer's warranty, equipment must be installed by a qualified licensed professional in accordance with local codes and the manufacturer's installation requirements.

2023 Energy Standards

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Department of Energy (DOE) State Regulations – Effective 2023

Click the link below to view the energy standards applicable to your region.

DOE State Standards Document

Documents & warranty
Warranty
10 Years Compressor & 10 Years Parts & 3 Years Unit Replacement | Registration Required within 60 Days of Installation
Frequently asked questions
Is the AHRI certified?
Yes. The AHRI reference number is 218396750.
What refrigerant does the use?
It uses R-32 refrigerant.
What size is the ?
The is a 2 ton unit.
How much cooling does the provide?
It is rated for 23,000 BTU of cooling.
What is the SEER2 rating of the ?
The is rated at 14 SEER2 SEER2.
What is the HSPF2 heating efficiency of the ?
It is rated at 7 HSPF2 HSPF2.
What power supply does the need?
It requires 208/230V 1-Phase power.
What warranty comes with the BAH17-24-15-LUC17-24-15?
10 Years Compressor & 10 Years Parts & 3 Years Unit Replacement | Registration Required within 60 Days of Installation
Who makes the BAH17-24-15-LUC17-24-15?
The BAH17-24-15-LUC17-24-15 is made by Comfortstar.
