Description
The Cooper & Hunter CH-R28MES-230VO is a 28,000 BTU multi-zone inverter heat pump condenser sold on its own for up to 4 indoor units.
AHRI reference (non-ducted indoor units): 215864257. Port adapters are included; branch boxes are not required. A minimum of two zones must be connected and each zone needs at least 10 ft of line.
Specifications
- Model: CH-R28MES-230VO
- Cooling Capacity, rated (min~max) BTU/h: 27,000 (7,200~32,000)
- Heating Capacity, rated (min~max) BTU/h: 27,000 (8,400~29,000)
- COP @ 47°F: 3.8
- HSPF2 (Region IV / V): 9.5 / 7.4
- Max Line Length (ft): 262.4
- Max Height Difference (ft): 49.2
- Refrigerant Pre-Charge: 100 ft of line
- Minimum Circuit Ampacity (A): 23
- Max Fuse / Breaker (A): 25
- Outdoor Sound Level (dB(A)): 61
- Cooling Operating Range (°F outdoor): -13~122
- Heating Operating Range (°F outdoor): -13~75
- Unit Dimensions (W x D x H): 37.24 in x 16.14 in x 31.89 in
- Net / Shipping Weight: 138.89 lb / 149.69 lb
- Maximum Indoor Units: 4
- Refrigerant Ports: 4 x 1/4" liquid / 3 x 3/8" + 1 x 1/2" gas
- Max Total Line Length (ft): 262.4
- Max Line Length to One Indoor Unit (ft): 114.8
Compatibility
Use only with Cooper & Hunter indoor units approved for this outdoor unit in the manufacturer's match-up and multi-zone combination charts. Indoor units, line sets, communication cable and installation materials are sold separately. Installation requires a licensed HVAC technician.
