Description
The Cooper & Hunter CH-R48MES-230VO is a 48,000 BTU multi-zone inverter heat pump condenser sold on its own for up to 6 indoor units.
AHRI reference (non-ducted indoor units): 215864263. Port adapters are included; branch boxes are not required. A minimum of two zones must be connected and each zone needs at least 10 ft of line.
Specifications
- Model: CH-R48MES-230VO
- Cooling Capacity, rated (min~max) BTU/h: 47,000 (12,000~55,000)
- Heating Capacity, rated (min~max) BTU/h: 48,000 (13,000~53,000)
- COP @ 47°F: 3.8
- HSPF2 (Region IV / V): 10.3 / 8
- Max Line Length (ft): 262.4
- Max Height Difference (ft): 49.2
- Refrigerant Pre-Charge: 150 ft of line
- Minimum Circuit Ampacity (A): 34
- Max Fuse / Breaker (A): 40
- Outdoor Sound Level (dB(A)): 63
- Cooling Operating Range (°F outdoor): -13~122
- Heating Operating Range (°F outdoor): -13~75
- Unit Dimensions (W x D x H): 37.48 in x 16.34 in x 52.48 in
- Net / Shipping Weight: 222.00 lb / 254.19 lb
- Maximum Indoor Units: 6
- Refrigerant Ports: 6 x 1/4" liquid / 4 x 3/8" + 2 x 1/2" gas
- Max Total Line Length (ft): 262.4
- Max Line Length to One Indoor Unit (ft): 114.8
Compatibility
Use only with Cooper & Hunter indoor units approved for this outdoor unit in the manufacturer's match-up and multi-zone combination charts. Indoor units, line sets, communication cable and installation materials are sold separately. Installation requires a licensed HVAC technician.
