Extra Information
Brand:
Goodman
Width:
14.00
(in)
Height:
34.00
(in)
Depth:
28.03
(in)
Weight:
100.00 LBS
Refrigerant Type:
R32
Prod Weight (lbs):
201.5
Voltage:
208 to 230
Product Category:
Gas Heating & Air Conditioner Bundle
Safety Information:
PROP 65 WARNING: This product and other products on our site may contain a chemical known to the State of California to cause cancer or birth defects or other reproductive harm.
Electrical Frequency:
60hz
SEER2 | Seasonal Energy Efficiency Ratio 2:
15.5
Electrical Phase:
1ph
EER2 | Energy Efficiency Ratio 2:
11.5
Configuration:
Downflow
Available Regions:
Nationwide - Except CA
Capacity (Tons):
5
AHRI Certified:
Yes
AHRI Reference Number:
215381101
AFUE%:
80
Cooling BTU | British Thermal Unit:
60,000
Cabinet Width (Inches):
21
Blower Motor Type:
ECM Multi-Speed
Brand:
Goodman
Color:
Gray
Air Flow (CFM):
2000
Gas Furnace Stages:
Single Stage
Line Set Connection Type:
Solder
Heating BTU:
80,000
Liquid Line Size | OD - Outside Diameter:
3/8
Prop 65 Warning:
Yes
Vent Type:
Chimney Vent
Ship Weight (lbs):
216.5
Warranty Information
10 Year Heat Exchanger & 10 Years Compressor & 10 Years Parts | Registration Required within 60 Days of Purchase
